Set Menu

Use the following subsections to perform the functions contained within
the S E T menu.

Reverting to the Factory Defaults

Studio Spot fixtures are shipped from High End Systems with the following
factory defaults:
• addressing by fixture number mode
• five minute fixture shutdown time
• display on (bright)
• pan invert off
• tilt invert off
• swap pan and tilt off
To revert to the factory defaults, complete the following procedure:
1. Hold <
2. Using the up and down buttons, scroll to the S E T field and press
<
ENTER
3. Press <
4. Using the up and down buttons, scroll to the O N field and press
<
ENTER
and home the fixture.

Addressing By DMX Starting Channel or Fixture Number Mode

To change the addressing method to DMX starting channel or to fixture
number mode, complete the following procedure:
1. Hold <
2. Using the up and down buttons, scroll to the S E T field and press
<
ENTER
3. Using the up and down buttons, scroll to the C H N L field and press
<
ENTER
4. Using the up and down buttons, select either A d d R (fixture number
mode) or d M X (DMX starting channel mode) and press <
3-26 Studio Spot User's Manual
> until the display changes to A d d R .
MENU
>. The display will indicate F A C T .
> again to enter the field.
ENTER
>. The fixture will return to the factory default listed above
> until the display changes to A d d R .
MENU
>.
>.
>.
ENTER
