Proline Prosonic Flow 93T Portable
Materials
Display elements
Operating elements
Language groups
Remote operation
Endress+Hauser
Transmitter
Plastic
Sensor Prosonic Flow P
DN 15 to 65 (½ to 2½")
• Sensor holder: corrosion protected aluminum, stainless steel 1.4301
• Sensor housing: stainless steel 1.4301
• Sensor contact surfaces: chemically stable plastic
DN 50 to 4000 (2 to 160")
• Sensor holder: stainless steel 1.4301
• Sensor housing: stainless steel 1.4301
• Strapping bands/bracket: textile or stainless steel 1.4301
• Sensor contact surfaces: chemically stable plastic
Sensor (accessories)
Prosonic Flow DDU18; Prosonic Flow DDU20
• Sensor holder: stainless steel 1.4301
• Sensor housing: stainless steel 1.4301
• Strapping bands/bracket: textile or stainless steel 1.4301
• Sensor contact surfaces: chemically stable plastic
Connecting cable (sensor/transmitter)
PTFE connecting cable
• Cable sheath: PTFE
• Cable connector: stainless steel

10.1.11 Human interface

• Liquid crystal display: illuminated, four lines each with 16 characters
• Custom configuration for presenting different measured values and status variables
• Local operation with three optical keys
• Application specific Quick Setup menus for straightforward commissioning
Language groups available for operation in different countries:
• Western Europe and America (WEA):
English, German, Spanish, Italian, French, Dutch and Portuguese
• Eastern Europe/Scandinavia (EES):
English, Russian, Polish, Norwegian, Finnish, Swedish and Czech
• South and Eastern Asia (SEA):
English, Japanese, Indonesian
• China (CN):
English, Chinese
You can change the language group via the FieldCare operating program.
Operation via FieldCare, with:
• Option of loading or saving preprogrammed measuring points
• Configuration logging
• Measured value visualization
Technical data
63
