Weight (US units)
Display elements
Operating elements
Language groups
!
Remote operation
84
Transmitter wall-mount housing: 13.2 lbs
Nominal diameter
[mm} [inch]
300 12"
350 14"
400 16"
– 18"
500 20"
600 24"
700 28"
– 30"
800 32"
900 36"
1000 40"
– 42"
1200 48"
– 54"
1400 –
– 60"
1600 –
– 66"
1800 72"
2000 78"
Weight information valid for standard pressure ratings and without packaging material. All weight information in [lbs]

10.1.11 Human interface

• Liquid crystal display: illuminated, four lines each with 16 characters
• Custom configuration for presenting different measured values and status variables
• 3 totalizers
• At ambient temperatures below –20 °C (–4 °F) the readability of the display may be impaired.
• Local operation with three optical sensor keys (S/O/F)
• Application-specific Quick Setup menus for straightforward commissioning
Language groups available for operation in different countries:
• Western Europe and America (WEA):
English, German, Spanish, Italian, French, Dutch and Portuguese
• Eastern Europe/Scandinavia (EES):
English, Russian, Polish, Norwegian, Finnish, Swedish and Czech.
• South and Eastern Asia (SEA):
English, Japanese, Indonesian
• China (CN):
English, Chinese
Note!
You can change the language group via the operating program "FieldCare".
Operation via FOUNDATION Fieldbus using a suitable configuration or operating software program
for this purpose
Proline Prosonic Flow 93C FOUNDATION Fieldbus
Measuring pipe incl. sensors
DIN DIN
PN 6 PN 10
– 92
– 121
– 146
– –
– 213
– 265
– 405
– –
– 540
– 692
– 836
– –
958 1496
– –
1255 2001
– –
1805 3046
– –
2191 3807
3326 5278
DIN ANSI
PN 16 Class 150
131 170
155 245
199 308
– 359
322 436
434 635
554 –
– –
721 –
1006 –
1295 –
– –
2076 –
– –
2795 –
– –
4436 –
– –
5751 –
7941 –
