Technical data
Surface roughness
Display elements
Operating elements
Language groups
!
174
Promag H
• With O-ring: weld nipples (DIN EN ISO 1127, ODT / SMS), flanges (EN (DIN), ANSI, JIS), PVDF
flanges (EN (DIN), ANSI, JIS), external pipe thread, internal pipe thread, hose connection, PVC
adhesive coupling
• With molded seal: weld nipples (DIN 11850, ODT / SMS), clamps (ISO 2852, DIN 32676, L14
AM7), threaded connection (DIN 11851, DIN 11864-1, ISO 2853, SMS 1145), flanges DIN
11864-2
• Measuring tube lined with PFA: ≤ 0.4 µm
• Electrodes: 0.3 to 0.5 µm
• Process connection Promag H: ≤ 0.8 µm
All specifications refer to wetted parts.

10.1.11 Human interface

• Liquid crystal display: illuminated, four lines with 16 characters per line
• Selectable display of different measured values and status variables
• 3 totalizers
• At ambient temperatures below -20 °C the readability of the display may be impaired.
• Local operation with three optical keys (S/O/F)
• Application-specific Quick Setup menus for straightforward commissioning
Language groups available for operation in different countries:
• Western Europe and America (WEA):
English, German, Spanish, Italian, French, Dutch and Portuguese
• Eastern Europe and Scandinavia (EES):
English, Russian, Polish, Norwegian, Finnish, Swedish and Czech.
• South and east Asia (SEA):
English, Japanese, Indonesian
• China (CN):
English, Chinese
Note!
You can change the language group via the operating program "ToF Tool - Fieldtool Package".
