Clutch
Overview of clutch
The clutch is used to transmit/disengage command pulses from the main/auxiliary shaft input side to the output axis module
through turning the clutch ON/OFF, which controls the operation/stop of the servomotor.
A clutch can be configured for the main and auxiliary shafts.
Control method for clutch
Set the ON and OFF control methods separately in "[Pr.405] Main shaft clutch control setting" and "[Pr.422] Auxiliary shaft
clutch control setting".
Although the clutch control setting can be changed during synchronous control, however, the setting "No clutch" (Direct
coupled operation) cannot be selected during synchronous control after already selecting another setting.
Item
Setting item
Main shaft clutch
Clutch control
[Pr.405]
setting
Main shaft clutch control
setting
*1 The range from axis 1 to 2 is valid in the 2-axis module, from axis 1 to 4 is valid in the 4-axis module, and from axis 1 to 8 is valid in the
8-axis module.
When the clutch ON condition and the clutch OFF condition are completed simultaneously within one operation cycle, both
clutch ON and OFF processing are executed within one operation cycle. Therefore, the clutch is from OFF to ON and again to
OFF at the clutch OFF status, and it is from ON to OFF and again to ON at the clutch ON status.
The following shows the operations for the clutch ON/OFF by the setting of the ON control mode and the OFF control mode.
ON control mode
■No clutch (Direct coupled operation)
Execute direct coupled operation without clutch control.
Other clutch parameters are not applicable during direct coupled operation by setting "0: No clutch". "Clutch
forced OFF command" and the change of the clutch control setting are ignored during direct coupled
operation.
Setting details/Setting value
Auxiliary shaft clutch
[Pr.422]
• Set the clutch control method.
Auxiliary shaft clutch control
■Set in hexadecimal.
setting
H _ _ _ _
ON control mode
0: No clutch
1: Clutch command ON/OFF
2: Clutch command leading edge
3: Clutch command trailing edge
4: Address mode
5: High speed input request
OFF control mode
0: OFF control invalid
1: One-shot OFF
2: Clutch command leading edge
3: Clutch command trailing edge
4: Address mode
5: High speed input request
High speed input request signal
0 to F: High speed input request
signal from axis 1 to axis 16
4 SYNCHRONOUS CONTROL
4
*1
77
4.3 Clutch
