Data Readouts - Danfoss VLT FC 100 Operating Instructions Manual

6 How to Programme

6.2.16 16-** Data Readouts

Par. Parameter description
No. #
16-0* General Status
16-00 Control Word
16-01 Reference [Unit]
16-02 Reference [%]
16-03 Status Word
16-05 Main Actual Value [%]
16-09 Custom Readout
16-1* Motor Status
16-10 Power [kW]
16-11 Power [hp]
16-12 Motor Voltage
6
16-13 Frequency
16-14 Motor Current
16-15 Frequency [%]
16-16 Torque [Nm]
16-17 Speed [RPM]
16-18 Motor Thermal
16-22 Torque [%]
16-26 Power Filtered [kW]
16-27 Power Filtered [hp]
16-3* Drive Status
16-30 DC Link Voltage
16-32 Brake Energy /s
16-33 Brake Energy /2 min
16-34 Heatsink Temp.
16-35 Inverter Thermal
16-36 Inv. Nom. Current
16-37 Inv. Max. Current
16-38 SL Controller State
16-39 Control Card Temp.
16-40 Logging Buffer Full
16-43 Timed Actions Status
16-49 Current Fault Source
16-5* Ref. & Feedb.
16-50 External Reference
16-52 Feedback [Unit]
16-53 Digi Pot Reference
16-54 Feedback 1 [Unit]
16-55 Feedback 2 [Unit]
16-56 Feedback 3 [Unit]
16-58 PID Output [%]
16-6* Inputs & Outputs
16-60 Digital Input
16-61 Terminal 53 Switch Setting
16-62 Analog Input 53
16-63 Terminal 54 Switch Setting
16-64 Analog Input 54
16-65 Analog Output 42 [mA]
16-66 Digital Output [bin]
16-67 Pulse Input #29 [Hz]
16-68 Pulse Input #33 [Hz]
150
Default value
0 N/A
0.000 ReferenceFeedbackUnit
0.0 %
0 N/A
0.00 %
0.00 CustomReadoutUnit
0.00 kW
0.00 hp
0.0 V
0.0 Hz
0.00 A
0.00 %
0.0 Nm
0 RPM
0 %
0 %
0.000 kW
0.000 hp
0 V
0.000 kW
0.000 kW
0 °C
0 %
ExpressionLimit
ExpressionLimit
0 N/A
0 °C
[0] No
[0] Timed Actions Auto
0 N/A
0.0 N/A
0.000 ProcessCtrlUnit
0.00 N/A
0.000 ProcessCtrlUnit
0.000 ProcessCtrlUnit
0.000 ProcessCtrlUnit
0.0 %
0 N/A
[0] Current
0.000 N/A
[0] Current
0.000 N/A
0.000 N/A
0 N/A
0 N/A
0 N/A
MG.11.F3.02 - VLT ® is a registered Danfoss trademark
VLT HVAC Drive High Power Operating In-
4-set-up Change Conver-
during op- sion index
eration
All set-ups FALSE 0
All set-ups FALSE -3
All set-ups FALSE -1
All set-ups FALSE 0
All set-ups FALSE -2
All set-ups FALSE -2
All set-ups FALSE 1
All set-ups FALSE -2
All set-ups FALSE -1
All set-ups FALSE -1
All set-ups FALSE -2
All set-ups FALSE -2
All set-ups FALSE -1
All set-ups FALSE 67
All set-ups FALSE 0
All set-ups FALSE 0
All set-ups FALSE 0
All set-ups FALSE -3
All set-ups FALSE 0
All set-ups FALSE 0
All set-ups FALSE 0
All set-ups FALSE 100
All set-ups FALSE 0
All set-ups FALSE -2
All set-ups FALSE -2
All set-ups FALSE 0
All set-ups FALSE 100
All set-ups TRUE -
All set-ups TRUE -
All set-ups TRUE 0
All set-ups FALSE -1
All set-ups FALSE -3
All set-ups FALSE -2
All set-ups FALSE -3
All set-ups FALSE -3
All set-ups FALSE -3
All set-ups TRUE -1
All set-ups FALSE 0
All set-ups FALSE -
All set-ups FALSE -3
All set-ups FALSE -
All set-ups FALSE -3
All set-ups FALSE -3
All set-ups FALSE 0
All set-ups FALSE 0
All set-ups FALSE 0
structions
Type
V2
Int32
Int16
V2
N2
Int32
Int32
Int32
Uint16
Uint16
Int32
N2
Int32
Int32
Uint8
Int16
Int32
Int32
Uint16
Uint32
Uint32
Uint8
Uint8
Uint32
Uint32
Uint8
Uint8
Uint8
Uint8
Uint8
Int16
Int32
Int16
Int32
Int32
Int32
Int16
Uint16
Uint8
Int32
Uint8
Int32
Int16
Int16
Int32
Int32
