6 How to Programme
Q3-30 Single Zone Int. Set Point
Configuration Mode
Par. 1-00
Reference/Feedback Unit
Par. 20-12
Par. 20-13 Minimum Reference/Feedb.
Maximum Reference/Feedb.
Par. 20-14
Terminal 54 Low Current
Par. 6-22
Par. 6-24 Terminal 54 Low Ref./Feedb. Value
Terminal 54 High Ref./Feedb. Value
Par. 6-25
Par. 6-26 Terminal 54 Filter Time Constant
Terminal 54 Live Zero
Par. 6-27
Live Zero Timeout Time
Par. 6-00
Par. 6-01 Live Zero Timeout Function
Setpoint 1
Par. 20-21
PID Normal/ Inverse Control
Par. 20-81
Par. 20-82 PID Start Speed [RPM]
PID Start Speed [Hz]
6 Par. 20-83
Par. 20-93 PID Proportional Gain
Par. 20-94 PID Integral Time
Closed Loop Type
Par. 20-70
Par. 20-71 PID Performance
PID Output Change
Par. 20-72
Minimum Feedback Level
Par. 20-73
Par. 20-74 Maximum Feedback Level
PID Autotuning
Par. 20-79
102
Q3-3 Closed Loop Settings
Q3-31 Single Zone Ext. Set Point
Configuration Mode
Par. 1-00
Reference/Feedback Unit
Par. 20-12
Par. 20-13 Minimum Reference/Feedb.
Maximum Reference/Feedb.
Par. 20-14
Terminal 53 Low Voltage
Par. 6-10
Par. 6-11 Terminal 53 High Voltage
Terminal 53 Low Current
Par. 6-12
Par. 6-13 Terminal 53 High Current
Terminal 53 Low Ref./Feedb. Value
Par. 6-14
Terminal 53 High Ref./Feedb. Value
Par. 6-15
Par. 6-22 Terminal 54 Low Current
Terminal 54 Low Ref./Feedb. Value
Par. 6-24
Terminal 54 High Ref./Feedb. Value
Par. 6-25
Par. 6-26 Terminal 54 Filter Time Constant
Terminal 54 Live Zero
Par. 6-27
Par. 6-00 Live Zero Timeout Time
Par. 6-01 Live Zero Timeout Function
PID Normal/ Inverse Control
Par. 20-81
Par. 20-82 PID Start Speed [RPM]
PID Start Speed [Hz]
Par. 20-83
PID Proportional Gain
Par. 20-93
Par. 20-94 PID Integral Time
Closed Loop Type
Par. 20-70
PID Performance
Par. 20-71
Par. 20-72 PID Output Change
Minimum Feedback Level
Par. 20-73
Par. 20-74 Maximum Feedback Level
PID Autotuning
Par. 20-79
MG.11.F3.02 - VLT ® is a registered Danfoss trademark
VLT HVAC Drive High Power Operating In-
Q3-32 Multi Zone / Adv
Configuration Mode
Par. 1-00
Reference 1 Source
Par. 3-15
Par. 3-16 Reference 2 Source
Feedback 1 Source
Par. 20-00
Feedback 1 Conversion
Par. 20-01
Par. 20-02 Feedback 1 Source Unit
Feedback 2 Source
Par. 20-03
Par. 20-04 Feedback 2 Conversion
Feedback 2 Source Unit
Par. 20-05
Feedback 3 Source
Par. 20-06
Par. 20-07 Feedback 3 Conversion
Feedback 3 Source Unit
Par. 20-08
Reference/Feedback Unit
Par. 20-12
Par. 20-13 Minimum Reference/Feedb.
Maximum Reference/Feedb.
Par. 20-14
Par. 6-10 Terminal 53 Low Voltage
Par. 6-11 Terminal 53 High Voltage
Terminal 53 Low Current
Par. 6-12
Par. 6-13 Terminal 53 High Current
Terminal 53 Low Ref./Feedb. Value
Par. 6-14
Terminal 53 High Ref./Feedb. Value
Par. 6-15
Par. 6-16 Terminal 53 Filter Time Constant
Terminal 53 Live Zero
Par. 6-17
Terminal 54 Low Voltage
Par. 6-20
Par. 6-21 Terminal 54 High Voltage
Terminal 54 Low Current
Par. 6-22
Par. 6-23 Terminal 54 High Current
Terminal 54 Low Ref./Feedb. Value
Par. 6-24
Terminal 54 High Ref./Feedb. Value
Par. 6-25
Par. 6-26 Terminal 54 Filter Time Constant
Terminal 54 Live Zero
Par. 6-27
Live Zero Timeout Time
Par. 6-00
Par. 6-01 Live Zero Timeout Function
Warning Feedback Low
Par. 4-56
Par. 4-57 Warning Feedback High
Feedback Function
Par. 20-20
Setpoint 1
Par. 20-21
Par. 20-22 Setpoint 2
PID Normal/ Inverse Control
Par. 20-81
PID Start Speed [RPM]
Par. 20-82
Par. 20-83 PID Start Speed [Hz]
PID Proportional Gain
Par. 20-93
Par. 20-94 PID Integral Time
Par. 20-70 Closed Loop Type
PID Performance
Par. 20-71
Par. 20-72 PID Output Change
Minimum Feedback Level
Par. 20-73
Maximum Feedback Level
Par. 20-74
Par. 20-79 PID Autotuning
