3.2.6 Rated Power

Frame size
Enclosure IP
protection
NEMA Type 1/ Type 12
Normal overload 110 - 132 kW at 400 V
rated power - (380 - 480 V)
110% overload tor- 45 - 160 kW at 690 V
que
Frame size E1
Enclo- IP 21/54
sure
protec-
NEMA Type 1/ Type 12
tion
Normal over-
315 - 450 kW at 400 V
load rated
(380 - 480 V)
power - 110%
450 - 630 kW at 690 V
overload tor-
(525-690 V)
que
NB!
The F frames have four different sizes, F1, F2, F3 and F4 The F1 and F2 consist of an inverter cabinet on the right and rectifier
cabinet on the left. The F3 and F4 have an additional options cabinet left of the rectifier cabinet. The F3 is an F1 with an additional
options cabinet. The F4 is an F2 with an additional options cabinet.
D1 D2
21/54 21/54
Type 1/ Type 12
150 - 250 kW at 400 V
(380 - 480 V)
200 - 400 kW at 690 V
(525-690 V) (525-690 V)
E2
00
Chassis
315 - 450 kW at 400 V
(380 - 480 V)
450 - 630 kW at 690 V
(525-690 V)
MG.11.F3.02 - VLT ® is a registered Danfoss trademark
D3
00
Chassis
110 - 132 kW at 400 V
(380 - 480 V)
45 - 160 kW at 690 V
(525-690 V)
F1/F3
F3 F1
21/54
Type 1/ Type 12
500 - 710 kW at 400 V 800 - 1000 kW at 400 V
(380 - 480 V)
710 - 900 kW at 690 V 1000 - 1400 kW at 690 V
(525-690 V)
3 Mechanical Installation
D4
3
00
Chassis
150 - 250 kW at 400 V
(380 - 480 V)
200 - 400 kW at 690 V
(525-690 V)
F2/F4
F4 F3
21/54
Type 1/ Type 12
(380 - 480 V)
(525-690 V)
23
