3 Mechanical Installation
3
F
E
Illustration 3.20: IP00 enclosure power connections positions of disconnect switch
The power cables are heavy and difficult to bend. Consider the optimum position of the frequency converter for ensuring easy instal-
lation of the cables.
Each terminal allows use of up to 4 cables with cable lugs or use of standard box lug. Earth is connected to relevant termination
point in the frequency converter.
Illustration 3.21: Terminal in details
NB!
Power connections can be made to positions A or B
32
D C B
MG.11.F3.02 - VLT
VLT HVAC Drive High Power Operating In-
0[0.0]
0[0.0] A
B B
104[4.1]
A
35[1.4]
B B
A
10[0.4]
0[0.0]
® is a registered Danfoss trademark
structions
0[0.0]
