VLT HVAC Drive High Power Operating In-
structions
Illustration 4.12: Inverter Cabinet, frame size F2 and F4
1) External Temperature Monitoring
2) AUX Relay
01 02 03
04 05 06
3) NAMUR
4) AUX Fan
100 101 102 103
L1 L2 L1 L2
5) Brake
-R +R
81 82
3
7
4, 8, 9
5
FASTENER TORQUE: M10 19 Nm (14 FT-LB)
U/T1 96 V/T2 97 W/T3 98
6
6)
7)
8)
9)
MG.11.F3.02 - VLT ® is a registered Danfoss trademark
1
2
FASTENER TORQUE: M10 19 Nm (14 FT-LB) FASTENER TORQUE: M10 19 Nm (14 FT-LB)
U/T1 96 V/T2 97 W/T3 98 U/T1 96 V/T2 97 W/T3 98
Motor
U V W
96 97 98
T1 T2 T3
NAMUR Fuse. See fuse tables for part numbers
Fan Fuses. See fuse tables for part numbers
SMPS Fuses. See fuse tables for part numbers
4 Electrical Installation
