VLT HVAC Drive High Power Operating In-
structions
IP21 (NEMA 1) / IP54
(NEMA 12)
Frame Frame
size D1 size D2
A 277 (10.9) 379 (14.9)
B 227 (8.9) 326 (12.8)
C 173 (6.8) 273 (10.8)
D 179 (7.0) 279 (11.0)
E 370 (14.6) 370 (14.6)
F 300 (11.8) 300 (11.8)
G 222 (8.7) 226 (8.9)
H 139 (5.4) 142 (5.6)
I 55 (2.2) 59 (2.3)
J 354 (13.9) 361 (14.2)
K 284 (11.2) 277 (10.9)
L 334 (13.1) 334 (13.1)
M 250 (9.8) 250 (9.8)
N 167 (6.6) 167 (6.6)
O 261 (10.3) 260 (10.3)
P 170 (6.7) 169 (6.7)
Q 120 (4.7) 120 (4.7)
R 256 (10.1) 350 (13.8)
S 308 (12.1) 332 (13.0)
T 252 (9.9) 262 (10.3)
U 196 (7.7) 192 (7.6)
V 260 (10.2) 273 (10.7)
Table 3.1: Cable positions as shown in drawings above. Dimensions in
mm (inch).
IP00 / Chassis
Frame Frame size
size D3 D4
119 (4.7) 122 (4.8)
68 (2.7) 68 (2.7)
15 (0.6) 16 (0.6)
20.7 (0.8) 22 (0.8)
363 (14.3) 363 (14.3)
293 (11.5) 293 (11.5)
215 (8.4) 218 (8.6)
131 (5.2) 135 (5.3)
48 (1.9) 51 (2.0)
347 (13.6) 354 (13.9)
277 (10.9) 270 (10.6)
326 (12.8) 326 (12.8)
243 (9.6) 243 (9.6)
159 (6.3) 159 (6.3)
261 (10.3) 261 (10.3)
170 (6.7) 170 (6.7)
120 (4.7) 120 (4.7)
98 (3.8) 93 (3.7)
301 (11.8) 324 (12.8)
245 (9.6) 255 (10.0)
189 (7.4) 185 (7.3)
260 (10.2) 273 (10.7)
