VLT HVAC Drive High Power Operating In-
structions
Mains Supply 3 x 525- 690 VAC
Typical Shaft output at 550 V
[kW]
Typical Shaft output at 575 V
[HP]
Typical Shaft output at 690 V
[kW]
Enclosure IP21
Enclosure IP54
Enclosure IP00
Output current
Continuous
(at 550 V) [A]
Intermittent (60 sec overload)
(at 550 V) [A]
Continuous
(at 575/ 690 V) [A]
Intermittent (60 sec overload)
(at 575/ 690 V) [A]
Continuous KVA
(at 550 V) [KVA]
Continuous KVA
(at 575 V) [KVA]
Continuous KVA
(at 690 V) [KVA]
Max. input current
Continuous
(at 550 V ) [A]
Continuous
(at 575 V) [A]
Continuous
(at 690 V) [A]
Max. cable size, mains, motor
and load share [mm
Max. cable size, brake [mm
(AWG)]
Max. external pre-fuses [A]
Estimated power loss
at rated max. load [W]
V
Estimated power loss
at rated max. load [W]
V
Weight,
enclosure IP21, IP 54 [kg]
Weight,
enclosure IP00 [kg]
Efficiency
Output frequency
Heatsink overtemp. trip
Power card ambient trip
P500
400
500
500
E1
E1
E2
523
575
500
550
498
498
598
504
482
482
4x240 (4x500 mcm)
2 (AWG)]
2 2 x 185
(2 x 350 mcm)
1 700
4) 6903
, 600
4) , 690 7249
263
221
4)
MG.11.F3.02 - VLT ® is a registered Danfoss trademark
7 General Specifications
P560 P630
450 500
600 650
560 630
E1 E1
E1 E1
E2 E2
596 630
656 693
570 630
627 693
568 600
568 627
681 753
574 607
549 607
549 607
4x240 (4x500 mcm) 4x240 (4x500 mcm)
2 x 185 2 x 185
(2 x 350 mcm) (2 x 350 mcm)
900 900
8343 9244
8727 9673
272 313
236 277
0.98
0 - 500 Hz
110 °C
68 °C
