3.4.12 Installation of Input Plate Options

This section is for the field installation of input option kits available for
frequency converters in all D and E frames.
Do not attempt to remove RFI filters from input plates. Damage may
occur to RFI filters if they are removed from the input plate.
380 - 480V
380 - 500V
D1 All D1 power sizes
D2 All D2 power sizes
E1 FC 102FC 102/ : 315 kW
FC 302: 250 kW
FC 102FC 102/ : 355 -
450 kW
FC 302: 315 - 400 kW
525 - 690V
D1 FC 102FC 102/ : 45-90
kW
FC 302: 37-75 kW
FC 102FC 102/ :
110-160 kW
FC 302: 90-132 kW
D2 All D2power sizes
E1 FC 102FC 102/ :
450-500 kW
FC 302: 355-400 kW
FC 102FC 102/ :
560-630 kW
FC 302: 500-560 kW
NB!
For further information, please see the Instruction
175R5795
Sheet,

3.4.13 Installation of D or E Loadshare Option

The loadshare option can be installed on frame sizes D1, D2, D3, D4,
E1 and E2.
NB!
Loadshare Terminal Kit Instructions,
Please see the
175R5637 (D frames) or 177R1114 (E frames), for
further information.
Fuses Disconnect Fuses RFI
176F8442 176F8450
176F8443 176F8441
176F0253 176F0255
176F0254 176F0256
Fuses Disconnect Fuses RFI
175L8829 175L8828
175L8442 175L8445
175L8827 175L8826
176F0253 176F0255
176F0254 176F0258
Ordering information
Frame size D1/D3: 176F8456
Frame size D2/D4: 176F8455
Frame size E1/E2: 176F1843
MG.11.F3.02 - VLT ® is a registered Danfoss trademark
3 Mechanical Installation
NB!
Where RFI filters are available, there are two differ-
ent type of RFI filters depending on the input plate
combination and the RFI filters interchangeable. Field
installable kits in certain cases are the same for all
voltages.
RFI Fuses
176F8444 176F8448
176F8445 176F8449
176F0257 176F0258
176F0257 176F0259
RFI Fuses
175L8777 NA
175L8777 NA
175L8825 NA
NA NA
NA NA
3
RFI Disconnect
Fuses
176F8446
176F8447
176F0260
176F0262
RFI Disconnect
Fuses
NA
NA
NA
NA
NA
