4 Electrical Installation
4.1.15 Mains Disconnectors - Frame Size D, E and F
Frame
size Power & Voltage
P110-P132 380-480V &
D1/D3 P110-P160 525-690V
P160-P250 380-480V &
D2/D4 P200-P400 525-690V
P315 380-480V & P450-
E1/E2 P630 525-690V
4
E1/E2 P355-P450 380-480V
P500 380-480V & P710-
F3 P800 525-690V
P560-P710 380-480V &
F3 P900 525-690V
P800-P1M0 380-480V &
F4 P1M0-P1M4 525-690V
4.1.16 F Frame circuit breakers
Fram
e size Power & Voltage
P500 380-480V & P710-
F3 P800 525-690V
P560-P710 380-480V &
F3 P900 525-690V
P800 380-480V & P1M0-
F4 P1M4 525-690V
F4 P1M0 380-480V
4.1.17 F Frame Mains Contactors
Frame
size Power & Voltage
P500-P560 380-480V &
F3 P710-P900 525-690V
F3 P 630-P710380-480V
P800-P1M0 380-480V &
F4 P1M0-P1M4 525-690V
4.1.18 Motor Insulation
For motor cable lengths ≤ the maximum cable length listed in the Gen-
eral Specifications tables the following motor insulation ratings are rec-
ommended because the peak voltage can be up to twice the DC link
voltage, 2.8 times the mains voltage, due to transmission line effects in
the motor cable. If a motor has lower insulation rating it recommended
to use a du/dt or sine wave filter.
70
Type
ABB OETL-NF200A or
OT200U12-91
ABB OETL-NF400A or
OT400U12-91
ABB OETL-NF600A
ABB OETL-NF800A
Merlin Gerin
NPJF36000S12AAYP
Merlin Gerin
NRK36000S20AAYP
Merlin Gerin
NRK36000S20AAYP
Type
Merlin Gerin
NPJF36120U31AABSCYP
Merlin Gerin
NRJF36200U31AABSCYP
Merlin Gerin
NRJF36200U31AABSCYP
Merlin Gerin
NRJF36250U31AABSCYP
Type
Eaton XTCE650N22A
Eaton XTCEC14P22B
Eaton XTCEC14P22B
