VLT HVAC Drive High Power Operating In-
structions
Buss-
Size/
mann Rating
Type
PN*
P500 170M7081 1600A,
700V
P560 170M7081 1600A,
700V
P630 170M7082 2000A,
700V
P710 170M7082 2000A,
700V
P800 170M7083 2500A,
700V
P1M0 170M7083 2500A,
700V
Table 4.4: Frame Size F, Line Fuses, 380-480V
Size/ Bussmann
Rating
Type PN*
P500 170M8611 1100A,
1000V
P560 170M8611 1100A,
1000V
P630 170M6467 1400A,
700V
P710 170M6467 1400A,
700V
P800 170M8611 1100A,
1000V
P1M0 170M6467 1400A,
700V
Table 4.5: Frame Size F, Inverter Module DC Link Fuses, 380-480V
*170M fuses from Bussmann shown use the -/80 visual indicator, -
TN/80 Type T, -/110 or TN/110 Type T indicator fuses of the same size
and amperage may be substituted for external use
**Any minimum 500V UL listed fuse with associated current rating may
be used to meet UL requirements.
Internal
Buss-
Siba
mann Op-
tion
20 695 32.1600 170M7082
20 695 32.1600 170M7082
20 695 32.2000 170M7082
20 695 32.2000 170M7082
20 695 32.2500 170M7083
20 695 32.2500 170M7083
Siba
20 781 32.1000
20 781 32.1000
20 681 32.1400
20 681 32.1400
20 781 32.1000
20 681 32.1400
