VLT HVAC Drive High Power Operating In-
structions
4-57 Warning Feedback High
Range:
999999.999 [ par. 4-56 - 999999.999 Proc-
ProcessCtr- essCtrlUnit]
lUnit*
4-64 Semi-Auto Bypass Set-up
Option:
[0] * Off
[1] Enabled
5-01 Terminal 27 Mode
Option:
[0] * Input
[1] Output
5-02 Terminal 29 Mode
Option:
[0] * Input
[1] Output
This parameter cannot be adjusted while the motor is running.
6.1.4 5-1* Digital Inputs
Parameters for configuring the input functions for the input terminals.
The digital inputs are used for selecting various functions in the
frequency converter. All digital inputs can be set to the following func-
tions
Digital input function Select
No operation
Reset
Coast inverse
Coast and reset inverse
DC-brake inverse
Stop inverse
External interlock
Start
Latched start
Reversing [10]
Start reversing [11]
Jog [14]
Preset reference on [15]
Preset ref bit 0 [16]
Preset ref bit 1 [17]
Preset ref bit 2 [18]
Freeze reference [19]
Freeze output [20]
Speed up [21]
Speed down [22]
Set-up select bit 0 [23]
Function:
Enter the upper feedback limit. When the feedback exceeds this limit, the display reads Feedb
High. The signal outputs can be programmed to produce a status signal on terminal 27 or 29 and
on relay output 01 or 02.
Function:
No function
Starts the Semi-Automatic Bypass set-up and continue with the procedure described above.
Function:
Defines terminal 27 as a digital input.
Defines terminal 27 as a digital output.
Function:
Defines terminal 29 as a digital input.
Defines terminal 29 as a digital output.
Terminal
[0] All *terminal 19, 32, 33
[1] All
[2] 27
[3] All
[5] All
[6] All
[7] All
[8] All *terminal 18
[9] All
All
All
All *terminal 29
All
All
All
All
All
All
All
All
All
MG.11.F3.02 - VLT ® is a registered Danfoss trademark
Digital input function Select
Set-up select bit 1 [24]
Pulse input [32]
Ramp bit 0 [34]
Mains failure inverse [36]
Fire mode [37]
Run Permissive [52]
Hand start [53]
Auto start [54]
DigiPot Increase [55]
DigiPot Decrease [56]
DigiPot Clear [57]
Counter A (up) [60]
Counter A (down) [61]
Reset Counter A [62]
Counter B (up) [63]
Counter B (down) [64]
Reset Counter B [65]
Sleep Mode [66]
Reset Maintenance Word [78]
PTC Card 1 [80]
Lead Pump Start [120]
Lead Pump Alternation [121]
Pump 1 Interlock [130]
Pump 2 Interlock [131]
Pump 3 Interlock [132]
6 How to Programme
6
Terminal
All
terminal 29, 33
All
All
All
All
All
All
All
All
All
29, 33
29, 33
All
29, 33
29, 33
All
All
All
All
All
All
All
All
All
111
