VLT HVAC Drive High Power Operating In-
structions
1-20 Motor Power [kW]
Range:
Size rela- [ 0.09 - 3000.00 kW]
ted*
1-21 Motor Power [HP]
Range:
Size rela- [ 0.09 - 3000.00 hp]
ted*
1-22 Motor Voltage
Range:
Size rela- [ 10. - 1000. V]
ted*
1-23 Motor Frequency
Range:
Size rela- [20 - 1000 Hz]
ted*
NB!
This parameter cannot be adjusted while the motor
is running.
1-24 Motor Current
Range:
Size rela- [ 0.10 - 10000.00 A]
ted*
This parameter cannot be adjusted while the motor
is running.
1-25 Motor Nominal Speed
Range:
Size rela- [100 - 60000 RPM]
ted*
This parameter cannot be adjusted while the motor
is running.
Function:
Enter the nominal motor power in kW according to the motor nameplate data. The default value
corresponds to the nominal rated output of the unit.
This parameter cannot be adjusted while the motor is running. Depending on the choices made in
Regional Settings , either par. 1-20 Motor Power [kW] or par. 1-21 Motor Power [HP] is
par. 0-03
made invisible.
Function:
Enter the nominal motor power in HP according to the motor nameplate data. The default value
corresponds to the nominal rated output of the unit.
This parameter cannot be adjusted while the motor is running.
Depending on the choices made in par. 0-03
[kW] or par. 1-21 Motor Power [HP] is made invisible.
Function:
Enter the nominal motor voltage according to the motor nameplate data. The default value corre-
sponds to the nominal rated output of the unit.
This parameter cannot be adjusted while the motor is running.
Function:
Select the motor frequency value from the motor nameplate data.For 87 Hz operation with
230/400 V motors, set the nameplate data for 230 V/50 Hz. Adapt par. 4-13
Limit [RPM] and par. 3-03 Maximum Reference to the 87 Hz application.
Function:
Enter the nominal motor current value from the motor nameplate data. This data is used for cal-
culating motor torque, motor thermal protection etc.
Function:
Enter the nominal motor speed value from the motor nameplate data. This data is used for calcu-
lating automatic motor compensations.
MG.11.F3.02 - VLT ® is a registered Danfoss trademark
6 How to Programme
Regional Settings , either par. 1-20 Motor Power
Motor Speed High
