8 Warnings and Alarms
519 Missing or invalid Barcode data in EEPROM
783 Parameter value outside of min/max limits
1024- A can-telegram that has to be sent, couldn't be sent
1279
1281 Digital Signal Processor flash timeout
1282 Power micro software version mismatch
1283 Power EEPROM data version mismatch
1284 Cannot read Digital Signal Processor software version
1299 Option SW in slot A is too old
1300 Option SW in slot B is too old
1302 Option SW in slot C1 is too old
1315 Option SW in slot A is not supported (not allowed)
1316 Option SW in slot B is not supported (not allowed)
1318 Option SW in slot C1 is not supported (not allowed)
1379 Option A did not respond when calculating Platform
Version.
1380 Option B did not respond when calculating Platform
Version.
1536 An exception in the Application Orientated Control is
registered. Debug information written in LCP
1792 DSP watchdog is active. Debugging of power part data
Motor Orientated Control data not transferred correctly
2049 Power data restarted
8
2064-20 H081x: option in slot x has restarted
72
2080-20 H082x: option in slot x has issued a powerup-wait
88
2096-21 H083x: option in slot x has issued a legal powerup-wait
04
2304 Could not read any data from power EEPROM
2305 Missing SW version from power unit
2314 Missing power unit data from power unit
2315 Missing SW version from power unit
2316 Missing io_statepage from power unit
2324 Power card configuration is determined to be incorrect
at power up
2330 Power size information between the power cards does
not match
2561 No communication from DSP to ATACD
2562 No communication from ATACD to DSP (state running)
2816 Stack overflow Control board module
2817 Scheduler slow tasks
2818 Fast tasks
2819 Parameter thread
2820 LCP Stack overflow
2821 Serial port overflow
2822 USB port overflow
2836 cfListMempool to small
3072-51 Parameter value is outside its limits
22
5123 Option in slot A: Hardware incompatible with Control
board hardware
5124 Option in slot B: Hardware incompatible with Control
board hardware
5125 Option in slot C0: Hardware incompatible with Control
board hardware
184
5126 Option in slot C1: Hardware incompatible with Control
board hardware
5376-62 Out of memory
31
ALARM 39, Heatsink sensor
No feedback from the heatsink temperature sensor.
The signal from the IGBT thermal sensor is not available on the power
card. The problem could be on the power card, on the gate drive card,
or the ribbon cable between the power card and gate drive card.
WARNING 40, Overload of Digital Output Terminal 27
Check the load connected to terminal 27 or remove short-circuit con-
nection. Check par. 5-00
Mode .
WARNING 41, Overload of Digital Output Terminal 29
Check the load connected to terminal 29 or remove short-circuit con-
nection. Check par. 5-00
Mode .
WARNING 42, Overload of Digital Output on X30/6 or Overload
of Digital Output on X30/7
For X30/6, check the load connected to X30/6 or remove short-circuit
connection. Check par. 5-32
For X30/7, check the load connected to X30/7 or remove short-circuit
connection. Check par. 5-33
ALARM 46, Power card supply
The supply on the power card is out of range.
There are three power supplies generated by the switch mode power
supply (SMPS) on the power card: 24V, 5V, +/- 18V. When powered
with 24V DC with the MCB 107 option, only the 24V and 5V supplies
are monitored. When powered with three phase mains voltage, all
three supplied are monitored.
WARNING 47, 24 V supply low
The 24V DC is measured on the control card. The external 24V DC
backup power supply may be overloaded, otherwise contact your
Danfoss supplier.
WARNING 48, 1.8 V supply low
The 1.8V DC supply used on the control card is outside of allowable
limits. The power supply is measured on the control card.
WARNING 49, Speed limit
When the speed is not within the specified range in par. 4-11 and par.
4-13. the drive will show a warning. When the speed is below the
specified limit in par. 1-86
or stopping) the drive will trip.
ALARM 50, AMA calibration failed
Contact your Danfoss supplier.
ALARM 51, AMA check Unom and Inom
The setting of motor voltage, motor current, and motor power is pre-
sumably wrong. Check the settings.
ALARM 52, AMA low Inom
The motor current is too low. Check the settings.
ALARM 53, AMA motor too big
The motor is too big for the AMA to be carried out.
ALARM 54, AMA motor too small
The motor is too small for the AMA to be carried out.
MG.11.F3.02 - VLT ® is a registered Danfoss trademark
VLT HVAC Drive High Power Operating In-
Digital I/O Mode and par. 5-01 Terminal 27
Digital I/O Mode and par. 5-02 Terminal 29
Term X30/6 Digi Out (MCB 101) .
Term X30/7 Digi Out (MCB 101) .
Trip Speed Low [RPM] (except when starting
structions
