VLT HVAC Drive High Power Operating In-
structions
Group no. Parameter group:
0-** Operation/Display
1-** Load/Motor
2-** Brakes
3-** References/Ramps
4-** Limits/Warnings
5-** Digital In/Out
6-** Analog In/Out
8-** Comm. and Options
9-** Profibus
10-** CAN Fieldbus
11-** LonWorks
13-** Smart Logic
14-** Special Functions
15-** FC Information
16-** Data Readouts
18-** Data Readouts 2
20-** FC Closed Loop
21-** Ext. Closed Loop
22-** Application Functions
23-** Time Actions
25-** Cascade Controller
26-** Analog I/O Option MCB 109
27-** Cascade CTL Option
29-** Water Application Functions
31-** Bypass Option
6.1.7 Changing Data
1. Press [Quick Menu] or [Main Menu] key.
▲ ▼
2.
Use [ ] and [ ] keys keys to find parameter group to edit.
3. Press [OK] key.
▲ ▼
4.
Use [ ] and [ ] keys to find parameter to edit.
5. Press [OK] key.
6.1.8 Changing a Text Value
If the selected parameter is a text value, change the text value by
means of the up/down navigation keys.
The up key increases the value, and the down key decreases the value.
Place the cursor on the value to be saved and press [OK].
After selecting a parameter group, choose a parameter by means of the
navigation keys.
The middle section on the GLCP display shows the parameter number
and name as well as the selected parameter value.
6.
7.
MG.11.F3.02 - VLT ® is a registered Danfoss trademark
740RPM
Basic Settings
0 -01 Language
[0] English
Illustration 6.3: Display example.
▲ ▼
Use [ ] and [ ] keys to select correct parameter setting. Or,
to move to digits within a number, use keys. Cursor indicates
▲
digit selected to change. [ ] key increases the value, [
decreases the value.
Press [Cancel] key to disregard change, or press [OK] key to
accept change and enter new setting.
740RPM
Basic Settings
0 -01 Language
[0] English
Illustration 6.4: Display example.
6 How to Programme
10.64A 1 [1]
0-0 *
6
▼
] key
10.64 A 1 [1]
0-0 *
