VLT Micro Drive FC 51

4.13. Parameter Group 16: Data Readouts

4.13.1. 16-** Data Readouts
Parameter group for data read-outs, e.g. actual references, voltages, control, alarm, warning and status words.
4.13.2. 16-0* General Status
Parameters for reading the general status, e.g. the calculated reference, the active control word, status.
16-00 Control Word
Range:
*
0 [0 - 65535]
16-01 Reference [Unit]
Range:
*
0.000 [-4999.000 - 4999.000]
16-02 Reference %
Range:
*
0.0 [-200.0 - 200.0%]
16-03 Status Word
Range:
*
0 [0 - 65535]
16-05 Main Actual Value %
Range:
*
0.00 [-100.00 - 100.00%]

4.13.3. 16-09 Custom Readout

16-09 Custom Readout
Range:
*
0.00 [0.00 - 9999.00%]
4.13.4. 16-1* Motor Status
Parameters for reading the motor status values.
16-10 Power [kW]
Range:
*
0 kW [0 - 99 kW]
16-11 Power [hp]
Range:
0 hp [0 - 99 hp ]
Function:
View latest valid control word sent to frequency converter via serial communication port.
Function:
View total remote reference. Total reference is sum of pulse, analog, preset, LCP potentiometer, local bus and
freeze reference.
Function:
View total remote reference in percent. Total reference is sum of pulse, analog, preset, LCP potentiometer, local
bus and freeze reference.
Function:
View status word sent to frequency converter via serial communication port.
Function:
View two-byte word sent with status word to bus Master reporting main actual value.
Function:
Customized readout based on the settings of par. 0-31, par. 0-32 and par. 4-14
Function:
View output power in kW.
Function:
View output power in hp.
