4-13 Motor Speed High Limit [RPM]
Range:
Size rela- [ par. 4-11 - 60000. RPM]
ted*
Max. output frequency cannot exceed 10% of the in-
verter switching frequency (par. 14-01
quency ).
4-11 Motor Speed Low Limit [RPM]
Range:
Size rela- [ 0 - par. 4-13 RPM]
ted*
3-11 Jog Speed [Hz]
Range:
Size rela- [ 0.0 - par. 4-14 Hz]
ted*

6.1.3 Function Set-ups

The Function set-up provides quick and easy access to all parameters required for the majority of VLT HVAC Drive applications including most VAV and
CAV supply and return fans, cooling tower fans, Primary, Secondary and Condenser Water Pumps and other pump, fan and compressor applications.
How to access Function set-up - example
Step 1: Turn on the frequency converter (yellow LED lights)
Status
28.8%
Auto Remote Running
Step 2: Press the [Quick Menus] button (Quick Menus choices appear).
Function:
Enter the maximum limit for motor speed. The Motor Speed High Limit can be set to correspond
to the manufacturer's maximum rated motor. The Motor Speed High Limit must exceed the set-
Motor Speed Low Limit [RPM] . Only par. 4-11 Motor Speed Low Limit [RPM] or
ting in par. 4-11
Motor Speed Low Limit [Hz] will be displayed depending on other parameters in the
par. 4-12
Main Menu and depending on default settings dependant on global location.
Switching Fre-
Function:
Enter the minimum limit for motor speed. The Motor Speed Low Limit can be set to correspond to
the manufacturer's recommended minimum motor speed. The Motor Speed Low Limit must not
exceed the setting in par. 4-13
Function:
The jog speed is a fixed output speed at which the frequency converter is running when the jog
function is activated.
Jog Ramp Time .
See also par. 3-80
1 (1)
2.63kW
5.66A
14.4Hz
0kWh
MG.11.F3.02 - VLT ® is a registered Danfoss trademark
Any changes in par. 4-13
[RPM] will reset the value in par. 4-53 Warning
Speed High to the same value as set in par. 4-13 Mo-
tor Speed High Limit [RPM] .
Motor Speed High Limit [RPM] .
13.7%
Quick Menus
Q1 My Personal Menu
Q2 Quick Setup
Q3 Function Setups
Q5 Changes Made
Step 3: Use the up/down navigation keys to scroll down to Function
set-ups. Press [OK].
6 How to Programme
Motor Speed High Limit
6
13.0A 1(1)
