VLT HVAC Drive High Power Operating In-
structions
Mains Supply 3 x 380 - 480 VAC
Typical Shaft output
at 400 V [kW]
Typical Shaft output
at 460 V [HP]
Enclosure IP21
Enclosure IP54
Enclosure IP00
Output current
Continuous
(at 400 V) [A]
Intermittent (60 sec
overload)
(at 400 V) [A]
Continuous
(at 460/ 480 V) [A]
Intermittent (60 sec
overload)
(at 460/ 480 V) [A]
Continuous KVA
(at 400 V) [KVA]
Continuous KVA
(at 460 V) [KVA]
Max. input current
Continuous
(at 400 V ) [A]
Continuous
(at 460/ 480 V) [A]
Max. cable size, mains
motor, brake and load
share [mm
Max. external pre-
1
fuses [A]
Estimated power loss
at rated max. load
[W] 4) , 400 V
Estimated power loss
at rated max. load
[W] 4) , 460 V
Weight,
enclosure IP21, IP 54
[kg]
Weight,
enclosure IP00 [kg]
4)
Efficiency
Output frequency
Heatsink overtemp.
trip
Power card ambient
trip
P110
110
150
D1
D1
D3
212
233
190
209
147
151
204
183
2 x 70
(2 x 2/0)
2 2)
(AWG )]
300
3234
2947
96
82
90 °C
MG.11.F3.02 - VLT ® is a registered Danfoss trademark
P132 P160
132 160
200 250
D1 D2
D1 D2
D3 D4
260 315
286 347
240 302
264 332
180 218
191 241
251 304
231 291
2 x 70 2 x 150
(2 x 2/0) (2 x 300 mcm)
350 400
3782 4213
3665 4063
104 125
91 112
0.98
0 - 800 Hz
110°C 110°C
60 °C
7 General Specifications
P200 P250
200 250
300 350
D2 D2
D2 D2
D4 D4
395 480
435 528
361 443
397 487
274 333
288 353
381 463
348 427
2 x 150 2 x 150
(2 x 300 mcm) (2 x 300 mcm)
500 630
5119 5893
4652 5634
136 151
123 138
110 °C
110°C
7
