6.2.14 14-** Special Functions

Par. Parameter description
No. #
14-0* Inverter Switching
14-00 Switching Pattern
14-01 Switching Frequency
14-03 Overmodulation
14-04 PWM Random
14-1* Mains On/Off
14-10 Mains Failure
14-11 Mains Voltage at Mains Fault
14-12 Function at Mains Imbalance
14-2* Reset Functions
14-20 Reset Mode
14-21 Automatic Restart Time
14-22 Operation Mode
14-23 Typecode Setting
14-25 Trip Delay at Torque Limit
14-26 Trip Delay at Inverter Fault
14-28 Production Settings
14-29 Service Code
14-3* Current Limit Ctrl.
14-30 Current Lim Ctrl, Proportional Gain
14-31 Current Lim Ctrl, Integration Time
14-32 Current Lim Ctrl, Filter Time
14-4* Energy Optimising
14-40 VT Level
14-41 AEO Minimum Magnetisation
14-42 Minimum AEO Frequency
14-43 Motor Cosphi
14-5* Environment
14-50 RFI Filter
14-51 DC Link Compensation
14-52 Fan Control
14-53 Fan Monitor
14-55 Output Filter
14-59 Actual Number of Inverter Units
14-6* Auto Derate
14-60 Function at Over Temperature
14-61 Function at Inverter Overload
14-62 Inv. Overload Derate Current
Default value
ExpressionLimit
ExpressionLimit
[1] On
[0] Off
[0] No function
ExpressionLimit
[0] Trip
ExpressionLimit
10 s
[0] Normal operation
ExpressionLimit
60 s
ExpressionLimit
[0] No action
0 N/A
100 %
0.020 s
26.0 ms
66 %
ExpressionLimit
10 Hz
ExpressionLimit
[1] On
[1] On
[0] Auto
[1] Warning
[0] No Filter
ExpressionLimit
[0] Trip
[0] Trip
95 %
MG.11.F3.02 - VLT ® is a registered Danfoss trademark
6 How to Programme
4-set-up Change Conver-
during op- sion index
eration
All set-ups TRUE -
All set-ups TRUE -
All set-ups FALSE -
All set-ups TRUE -
All set-ups FALSE -
All set-ups TRUE 0
All set-ups TRUE -
All set-ups TRUE -
All set-ups TRUE 0
All set-ups TRUE -
2 set-ups FALSE -
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE -
All set-ups TRUE 0
All set-ups FALSE 0
All set-ups FALSE -3
All set-ups TRUE -4
All set-ups FALSE 0
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE -2
1 set-up FALSE -
1 set-up TRUE -
All set-ups TRUE -
All set-ups TRUE -
1 set-up FALSE -
1 set-up FALSE 0
All set-ups TRUE -
All set-ups TRUE -
All set-ups TRUE 0
Type
Uint8
Uint8
Uint8
Uint8
Uint8
Uint16
Uint8
Uint8
6
Uint16
Uint8
Uint8
Uint8
Uint8
Uint8
Int32
Uint16
Uint16
Uint16
Uint8
Uint8
Uint8
Uint16
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint16
147
