6 How to Programme
[1] Analog input 53
[2] Analog input 54
[7] Pulse input 29
[8] Pulse input 33
[20] * Digital pot.meter
[21] Analog input X30/11
[22] Analog input X30/12
[23] Analog Input X42/1
[24] Analog Input X42/3
[25] Analog Input X42/5
[29] Analog Input X48/2
[30] Ext. Closed Loop 1
[31] Ext. Closed Loop 2
[32] Ext. Closed Loop 3
6
4-10 Motor Speed Direction
Option:
[0] Clockwise
[2] * Both directions
The setting in par. 4-10
impact on the Flying Start in par. 1-73
4-53 Warning Speed High
Range:
Size rela- [ par. 4-52 - par. 4-13 RPM]
ted*
Any changes in par. 4-13
[RPM] will reset the value in par. 4-53 Warning
Speed High to the same value as set in par. 4-13 Mo-
tor Speed High Limit [RPM] .
If a different value is needed in par. 4-53
Speed High , it must be set after programming of
par. 4-13
4-56 Warning Feedback Low
Range:
-999999.99 [ -999999.999 - par. 4-57 Proc-
9 Proc- essCtrlUnit]
essCtrlU-
nit*
110
Function:
Selects the motor speed direction required.
Use this parameter to prevent unwanted reversing.
Only operation in clockwise direction will be allowed.
Operation in both clockwise and anti-clockwise direction will be allowed.
Motor Speed Direction has
Flying Start .
Function:
Enter the n
HIGH
HIGH. The signal outputs can be programmed to produce a status signal on terminal 27 or 29
and on relay output 01 or 02. Programme the upper signal limit of the motor speed, n
the normal working range of the frequency converter. Refer to par. .
Motor Speed High Limit
Warning
Motor Speed High Limit [RPM]
Function:
Enter the lower feedback limit. When the feedback falls below this limit, the display reads Feedb
Low. The signal outputs can be programmed to produce a status signal on terminal 27 or 29 and
on relay output 01 or 02.
MG.11.F3.02 - VLT
VLT HVAC Drive High Power Operating In-
value. When the motor speed exceeds this limit (n
® is a registered Danfoss trademark
structions
), the display reads SPEED
HIGH
, within
HIGH
