Danfoss VLT FC 100 Operating Instructions Manual page 120

VLT HVAC Drive High Power Operating In-
structions
[101] Reference Min-Max
[102] Feedback +-200%
[103] Motor cur. 0-Imax
[104] Torque 0-Tlim
[105] Torque 0-Tnom
[106] Power 0-Pnom
[107] Speed 0-HighLim
[113] Ext. Closed Loop 1
[114] Ext. Closed Loop 2
[115] Ext. Closed Loop 3
[130] Out frq 0-100 4-20mA
[131] Reference 4-20mA
[132] Feedback 4-20mA
[133] Motor cur. 4-20mA
[134] Torq.0-lim 4-20 mA
[135] Torq.0-nom 4-20mA
[136] Power 4-20mA
[137] * Speed 4-20mA
[139] Bus ctrl.
[140] Bus ctrl. 4-20 mA
[141] Bus ctrl t.o.
[142] Bus ctrl t.o. 4-20mA
[143] Ext. CL 1 4-20mA
[144] Ext. CL 2 4-20mA
[145] Ext. CL 3 4-20mA
Values for setting the Minimum Reference is found in
open loop par. 3-02
closed loop par. 20-13
values for maximum reference for open loop is found
Maximum Reference and for closed loop
in par. 3-03
Maximum Reference/Feedb. .
par. 20-14
6-51 Terminal 42 Output Min Scale
Range:
0.00 %* [0.00 - 200.00 %]
Minimum reference - Maximum reference, (0-20 mA)
-200% to +200% of par. 20-14
0 - Inverter Max. Current (par. 16-37
0 - Torque limit (par. 4-16
0 - Motor rated torque, (0-20 mA)
0 - Motor rated power, (0-20 mA)
0 - Speed High Limit (par. 4-13
Limit [Hz] ), (0-20 mA)
0 - 100%, (0-20 mA)
0 - 100%, (0-20 mA)
0 - 100%, (0-20 mA)
0 - 100 Hz
Minimum Reference - Maximum Reference
-200% to +200% of par. 20-14
0 - Inverter Max. Current (par. 16-37
0 - Torque limit (par. 4-16
0 - Motor rated torque
0 - Motor rated power
0 - Speed High Limit (4-13 and 4-14)
0 - 100%, (0-20 mA)
0 - 100%
0 - 100%, (0-20 mA)
0 - 100%
0 - 100%
0 - 100%
0 - 100%
Minimum Reference and for
Minimum Reference/Feedb. -
Function:
Scale for the minimum output (0 or 4mA) of the analog signal at terminal 42.
Set the value to be the percentage of the full range of the variable selected in par. 6-50
42 Output .
MG.11.F3.02 - VLT ® is a registered Danfoss trademark
Maximum Reference/Feedb. , (0-20 mA)
Inv. Max. Current ), (0-20 mA)
Torque Limit Motor Mode ), (0-20 mA)
Motor Speed High Limit [RPM] and par. 4-14 Motor Speed High
Maximum Reference/Feedb.
Inv. Max. Current )
Torque Limit Motor Mode )
6 How to Programme
6
Terminal
119
