6 How to Programme
2-10 Brake Function
Option:
[0] * Off
[1] Resistor brake
6
[2] AC brake
2-17 Over-voltage Control
Option:
[0] Disabled
[2] * Enabled
Par. 2-17
when par. 1-10
lient SPM.
3-02 Minimum Reference
Range:
Size rela- [ -999999.999 - par. 3-03 Refer-
ted* enceFeedbackUnit]
3-04 Reference Function
Option:
[0] * Sum
[1] External/Preset
3-10 Preset Reference
Array [8]
Range:
0.00 %* [-100.00 - 100.00 %]
108
Function:
Available selections depend on par. 1-10
[0] Asynchron:
[0] off
[1] Resistor brake
[2] AS brake
[1] PM non salient:
[0] off
[1] Resistor brake
No brake resistor installed.
Brake resistor incorporated in the system, for dissipation of surplus brake energy as heat. Con-
necting a brake resistor allows a higher DC link voltage during braking (generating operation).
The Resistor brake function is only active in frequency converters with an integral dynamic brake.
AC Brake will only work in Compressor Torque mode in par. 1-03
Function:
No OVC required.
Activates OVC.
Over-voltage Control will not have effect
Motor Construction = [1] PM, non sa-
Function:
Enter the Minimum Reference. The Minimum Reference is the lowest value obtainable by sum-
ming all references. The Minimum Reference value and unit matches the configuration choice
made in par. 1-00
Function:
Sums both external and preset reference sources.
Use either the preset or the external reference source.
Shift between external and preset via a command on a digital input.
Function:
Enter up to eight different preset references (0-7) in this parameter, using array programming.
The preset reference is stated as a percentage of the value Ref
ence , for closed loop see par. 20-14 Maximum Reference/Feedb. ). When using preset references,
select Preset ref. bit 0 / 1 / 2 [16], [17] or [18] for the corresponding digital inputs in parameter
group 5-1* Digital Inputs.
MG.11.F3.02 - VLT
VLT HVAC Drive High Power Operating In-
Motor Construction :
The ramp time is automatically adjusted to avoid
tripping of the frequency converter.
Configuration Mode and par. 20-12 Reference/Feedback Unit , respectively.
This parameter is used in open loop only.
® is a registered Danfoss trademark
structions
Torque Characteristics .
Maximum Refer-
(par. 3-03
MAX
