VLT HVAC Drive High Power Operating In-
structions
Function Set-ups parameters
The Function Set-ups parameters are grouped in the following way
Q3-10 Adv. Motor Settings
Motor Thermal Protec-
Par. 1-90
tion
Thermistor Source
Par. 1-93
Automatic Motor Adap-
Par. 1-29
tation (AMA)
Par. 14-01 Switching Frequency
Warning Speed High
Par. 4-53
Q3-20 Digital Reference
Par. 3-02 Minimum Reference
Maximum Reference
Par. 3-03
Preset Reference
Par. 3-10
Par. 5-13 Terminal 29 Digital Input
Terminal 32 Digital Input
Par. 5-14
Par. 5-15 Terminal 33 Digital Input
Q3-1 General Settings
Q3-11 Analog Output Q3-12 Clock Settings
Terminal 42 Output
Par. 6-50 Par. 0-70
Terminal 42 Output Min
Par. 6-51 Par. 0-71
Scale
Terminal 42 Output Max
Par. 6-52 Par. 0-72
Scale
Par. 0-74
Par. 0-76
Par. 0-77
Q3-2 Open Loop Settings
MG.11.F3.02 - VLT ® is a registered Danfoss trademark
Q3-13 Display Settings
Date and Time
Par. 0-20
Date Format
Par. 0-21
Time Format
Par. 0-22
DST/Summertime Par. 0-23
DST/Summertime Start
Par. 0-24
DST/Summertime End
Par. 0-37
Par. 0-38
Par. 0-39
Q3-21 Analog Reference
Par. 3-02 Minimum Reference
Maximum Reference
Par. 3-03
Terminal 53 Low Voltage
Par. 6-10
Par. 6-11 Terminal 53 High Voltage
Terminal 53 Low Current
Par. 6-12
Par. 6-13 Terminal 53 High Current
Terminal 53 Low Ref./Feedb. Value
Par. 6-14
Terminal 53 High Ref./Feedb. Value
Par. 6-15
6 How to Programme
Display Line 1.1 Small
Display Line 1.2 Small
Display Line 1.3 Small
Display Line 2 Large
Display Line 3 Large
Display Text 1
Display Text 2
Display Text 3
