4 Electrical Installation
4
EARTH
TERMINALS
Illustration 4.5: Position of earth terminals IP00, frame
sizes D
EARTH
TERMINALS
Illustration 4.6: Position of earth terminals IP21 (NEMA
type 1) and IP54 (NEMA type 12)
NB!
D2 and D4 shown as examples. D1 and D3 are
equivalent.
54
MG.11.F3.02 - VLT
®
is a registered Danfoss trademark
VLT HVAC Drive High Power Operating In-
structions
