VLT HVAC Drive High Power Operating In-
structions
NB!
Please see the instruction for
NEMA 3R kit of industrial enclosures, 175R1068, for
further information.

3.4.7 Installation of IP00 to IP20 Kits

The kits can be installed on frame sizes D3, D4, and E2 (IP00).
NB!
Please see the instruction for Installation of IP20
Kits, 175R1108, for further information.
3.4.8 Installation of IP00s D3, D4, & E2 Cable Clamp Bracket
The motor cable clamp brackets can be installed on frame sizes D3 and
D4 (IP00).
NB!
Please see the instruction for
175R1109, for further information.

3.4.9 Installation on Pedestal

This section describes the installation of a pedestal unit available for
the frequency converters frames D1 and D2. This is a 200 mm high
pedestal that allows these frames to be floor mounted. The front of the
pedestal has openings for input air to the power components.
The frequency converter gland plate must be installed to provide ade-
quate cooling air to the control components of the frequency converter
via the door fan and to maintain the IP21/NEMA 1 or IP54/NEMA 12
degrees of enclosure protections.
Ordering information
Frame size D3: 176F0296
Outside Installation /
Frame size D4: 176F0295
Frame size E2: 176F0298
Ordering information
Frame size D3/D4: 176F1779
Frame size E2: 176FXXXX
Ordering information
Frame size D3: 176F1774
Frame size D4: 176F1746
Frame size E2: 176F1745
Cable Clamp Bracket Kit,
MG.11.F3.02 - VLT ® is a registered Danfoss trademark
3 Mechanical Installation
3
45
