7 General Specifications
Mains Supply 3 x 525 - 690 VAC
7
Max. input current
172
Typical Shaft output at 550 V
[kW]
Typical Shaft output at 575 V
[HP]
Typical Shaft output at 690 V
[kW]
Enclosure IP21
Enclosure IP54
Enclosure IP00
Output current
Continuous
(at 550 V) [A]
Intermittent (60 sec overload)
(at 550 V) [A]
Continuous
(at 575/ 690 V) [A]
Intermittent (60 sec overload)
(at 575/ 690 V) [A]
Continuous KVA
(at 550 V) [KVA]
Continuous KVA
(at 575 V) [KVA]
Continuous KVA
(at 690 V) [KVA]
Continuous
(at 550 V ) [A]
Continuous
(at 575 V) [A]
Continuous
(at 690 V) [A]
Max. cable size, mains, motor
2
and load share [mm (AWG)]
2
Max. cable size, brake [mm
(AWG)]
1
Max. external pre-fuses [A]
Estimated power loss
4)
at rated max. load [W] , 600
V
Estimated power loss
4)
at rated max. load [W] , 690
V
Weight,
enclosure IP21, IP 54 [kg]
Weight,
enclosure IP00 [kg]
Efficiency 4)
Output frequency
Heatsink overtemp. trip
Power card ambient trip
MG.11.F3.02 - VLT
VLT HVAC Drive High Power Operating In-
P315 P400
250 315
350 400
315 400
D2 D2
D2 D2
D4 D4
360 418
396 460
344 400
378 440
343 398
343 398
411 478
355 408
339 390
352 400
2 x 150 2 x 150
(2 x 300 mcm) (2 x 300 mcm)
2 x 150 2 x 150
(2 x 300 mcm) (2 x 300 mcm)
500 550
5493 5852
5821 6149
151 165
138 151
0.98
0 - 600 Hz 0 - 500 Hz
110 °C 110 °C
60 °C 60 °C
® is a registered Danfoss trademark
structions
P450
355
450
450
E1
E1
E2
470
517
450
495
448
448
538
453
434
434
4 x 240
(4 x 500 mcm)
2 x 185
(2 x 350 mcm)
700
6132
6440
263
221
0 - 500 Hz
110 °C
68 °C
