5.7.2

Default Test Card Selection

Enabling or disabling test cards for the default test is done using the Default
How to get there:
Test Card Selection option from the Setting Menu. In this case, the test card
Press the Main soft key in
selection made in this page becomes effective when starting a new CT test.
any test card
Main Menu:
If you want to enable or disable test cards for your currently active test only,
- Settings
press the Select Cards soft key in the CT-Object card. In this case, the test card
Select soft key
selection made in this page is immediately effective after pressing the Back soft
Setting Menu:
key.
- Default Test Card
Selection
To enable or disable a test card, select its entry using the
Select soft key
and then press the Add or Remove soft key. Enabled cards are marked with a
-> Select Cards page
checkmark, see Figure 5-10.
Figure 5-10
Some cards require the existence of other cards. This means that if you are
adding such a card, the required other cards are automatically added, too. On
the other hand, if you remove a card which is required by another card, the other
card is removed, too. Figure 5-11 shows these dependencies.
Operating and Configuring the CT Analyzer
Select Cards page for selecting the default test cards
cursor keys
69
