CT SB2 User Manual
42
Parameter
Description
VA
Use this column to set the nominal burden for each tap
combination.
cos ϕ
To obtain correct measurement results, the nominal
burdens for the inner tap combinations (e.g. X1-X2 etc.)
should be smaller than the nominal burden for the full tap
combination according to the winding ratios of the tap
combinations (e.g. 25VA for X1-X5, 12.5VA for X1-X4 etc.).
The CT Analyzer supports this with an automatic function.
As soon as the primary current I
combination, the CT Analyzer automatically calculates and
sets the corresponding nominal burden and cos ϕ for this
tap combination. For this, the CT Analyzer automatically
scales down the nominal burden for the full tap combination
according to the ratio of the specific tap combination and
rounds it to the next value stated in the standard (see Figure
6-3 on page 38).
The nominal burden (VA) automatically assigned by the
CT Analyzer can be changed manually by the user for all
tap and intertap combinations except the full tap
combination. The cos ϕ cannot be changed by the user.
Note: The "VA" column is displayed by default when
opening the MR-Config. card the first time after initializing a
new multi-ratio test. If the "Burden" column is displayed
instead, use the Nom. Burden soft key to display the "VA"
column with the nominal burdens again.
Burden
The "Burden" column is displayed if you selected to display
the operating burden in the MR-Config. card using the Op.
cos ϕ
Burden soft key.
This column displays the operating burden for the tap
combination. The operating burden is taken from the
CT-Object card and cannot be changed in the MR-Config.
card. The same value is used for all tap combinations to test
the behavior of the CT with the connected burden.
is specified for a tap
pn
