Connections required:
1 2 3 4 5 6 7 8 shield
1 2 3 4 5 6 7 8 shield
Figure 10-2
10.7.2

USB Interface

The USB interface can be used to connect the CT Analyzer to a computer.
Communication via USB is considerably faster than communication via RS232.
Figure 10-3
10.8

Environmental Conditions

10.8.1

Climate

9-pole (DB9) null modem or
crossover cable, 2 x female
Connection cable for RS232 remote control interface
USB interface
(type B connector)
USB remote control interface (standard type B connector)
Climate
Operating temperature
Storage and transportation
Max. altitude
Humidity
–10 ... +50°C (14 ... 122°F)
–25 ... +70°C (–13 ... 158°F)
2000m
5 ... 95% relative humidity, non-condensing
Tested acc. to IEC 60068-2-78, Cab,
Damp Heat: Temp. 40°C, duration 48 h, rel.
humidity 95%
Technical Data
