Note: In the CT Analyzer file system, the root directory can contain a maximum
of 240 files and the file name length (incl. the path) is limited to 240 characters.
5.6.2

Working in the File System

After selecting one of the available file operation functions in the File Menu, the
How to get there:
file system card is displayed showing the current path in its title bar and the file
Press the Main soft key in
system elements in the card area (refer to Figure 5-7).
any test card
Main Menu:
- File Handling Navigating in the file system
Select soft key
•
File Menu:
- Load Report or
- Save As or
- Delete File or •
- Rename File or
- Copy File(s) or
- Cut File(s) or
- Paste File(s)
Figure 5-7
Creating a new folder
How to get there:
Creating a new folder is only possible for the functions Save As and
Press the Main soft key in
any test card
Paste File(s) of the File Menu.
Main Menu:
To create a new folder in the file system, select Save As or Paste Files(s) in the
- File Handling
file menu and then navigate to the desired location in the file system where you
Select soft key
File Menu:
want to create the new folder. Then press the New Dir soft key. A new folder
- Save As or
with an empty name is created. Enter a name for the folder and press the
- Paste File(s)
key.
Figure 5-8
Note: In the CT Analyzer file system, a directory can contain a maximum of 240
files and the maximum file name length is 240 characters. Renaming of folders
is not supported by the CT Analyzer.
To open a folder, select its entry (see Figure 5-7, left) using the
cursor keys and then press the
To go one level higher in the directory structure, select the "one level higher"
entry and then press the
File system card for loading a report
File system card after creating a new folder
Operating and Configuring the CT Analyzer
key.
key.
63
