- Page 1 SPECTANO 100 Quick Start Guide Smart Measurement Solutions ®...
-
Page 2: Table Of Contents
Install SPECTANO Analyzer Suite ..............20 Power up SPECTANO 100 ................21 Connect SPECTANO 100 to the computer ............21 Connect SPECTANO 100 to a test object ............22 7.4.1 Typical setup for a test cell with guard ring ............25 7.4.2... - Page 3 SPECTANO 100 Quick Start Guide Connect SPECTANO 100 to the DTS1 dielectric test sample box ....28 Connect SPECTANO 100 to the Dielectric Sample Holder DSH 100 ....29 Support ......................31 Technical support – get support ............... 31...
-
Page 4: About This Quick Start Guide
About this Quick Start Guide This SPECTANO 100 Quick Start Guide provides short information on how to install and use SPECTANO 100. It is intended as an aid for the user to install SPECTANO 100 and take it into operation quickly and easily. The SPECTANO 100 Quick Start Guide thus provides only a small subset of information available for SPECTANO 100. -
Page 5: Safety Instructions
Operator qualifications and safety standards Testing and measuring with SPECTANO 100 and its accessories like the DTS1 dielectric test sample box must be carried out only by qualified, skilled and authorized personnel working with voltages up to 200 V AC and DC. -
Page 6: Five Safety Rules
► Only use the delivered grounded AC power supply DRA SUPPLY to power SPECTANO 100. Never use power outlets without protective ground (PE). ► Always turn off SPECTANO 100 (with the power switch on the back) before connecting or disconnecting any cables or changing the test cell. Be especially careful when using unsafe adapter cables (for example, BNC adapter). -
Page 7: Orderly Measures
SPECTANO 100 and its accessories like the DTS1 dielectric test sample box may be used only as described in the SPECTANO 100 Quick Start Guide or the User Manual. Any other use is not in accordance with the local safety regulations. -
Page 8: Disclaimer
If SPECTANO 100 or its accessories are used in a manner not specified by the manufacturer or used with third party test devices and cables, the protection provided by SPECTANO 100 or its accessories may be impaired, and this may result in damage to property or persons. -
Page 9: Compliance Statements And Recycling
SPECTANO 100 Quick Start Guide Compliance statements and recycling Compliance statements Declaration of conformity (EU) The equipment adheres to the guidelines of the council of the European Community for meeting the requirements of the member states regarding the electromagnetic compatibility (EMC) directive, the low voltage directive (LVD) and the RoHS directive. -
Page 10: Pc Requirements
PC requirements PC requirements The following table shows the minimum requirements your computer needs to run SPECTANO Analyzer Suite. Table 4-1 SPECTANO Analyzer Suite PC requirements Characteristic Requirement Processor Current Intel or Intel compatible CPU Memory (RAM) 2 GB, 4 GB recommended Graphics resolution Super VGA (1024×768), higher resolution recommended... -
Page 11: Introduction
SPECTANO 100 Quick Start Guide Introduction SPECTANO 100 SPECTANO 100, in conjunction with its accessories or as stand-alone unit, is a test system for dielectric analysis of solid and liquid materials. It combines the time-domain and frequency-domain analysis within a wide frequency range from 20 μHz up to 5 kHz in one device and provides an output voltage range from... -
Page 12: Dts1 Dielectric Test Sample Box
Introduction DTS1 dielectric test sample box The DTS1 dielectric test sample box is an accessory to SPECTANO 100 for demonstrating and testing the functionality of SPECTANO 100 without a sample test cell. The DTS1 is a demo box containing two samples: a high-precision, low-loss 1 nF capacitor and a RC circuit simulating a dielectric sample with losses. -
Page 13: Combined Mode (Fds And Pdc)
100 mHz. This reduces the measurement time up to 75% compared to exclusive FDS measurements. For example, a FDS measurement from 1 kHz to 100 µHz will take 11 hours, SPECTANO 100 will acquire this data in less than 3 hours using the combined FDS and PDC measurement. The maximum test frequency range for the combined mode is 20 µHz to 5 kHz. -
Page 14: Scope Of Delivery And Ordering Information
Introduction Scope of delivery and ordering information 5.7.1 Main package Description Part No. Picture SPECTANO 100 main device OL000400 DTS1 dielectric sample test box 2 ×Triaxial standard cable (1.5 m) Specific grounded SPECTANO 100 power supply CD ROM incl.SPECTANO Analyzer Suite and User... -
Page 15: Optional Accessories
SPECTANO 100 Quick Start Guide 5.7.2 Optional accessories Description Part No. Picture 2 ×Triaxial-to-4 mm plug OL000451 adapter cable set 2 ×Triaxial-to-BNC connector OL000452 adapter cable set... -
Page 16: Device Description
► Always ensure that no dangerous voltages are present at any touchable part of the device. ► Before handling SPECTANO 100 in any way, connect its equipotential ground terminal with a solid connection of at least 6 mm cross-section and not longer than 20 meters to the ground terminal in the laboratory. - Page 17 • An error has occurred during measurement (Measurement is stopped.). After a computer has been connected to SPECTANO 100, the error information is sent to the computer and the LED is on. Signals dangerous voltage on the OUTPUT...
- Page 18 ► Only use the delivered grounded AC power supply DRA SUPPLY to power SPECTANO 100. ► Connect the SPECTANO 100 power supply only to a power outlet that is equipped with protective ground (PE). ► For safe operation always make sure that protective ground and equipotential ground are connected properly.
-
Page 19: Cleaning
DANGER Death or severe injury caused by high voltage or current ► Use the DTS1 box only together with the SPECTANO 100 test device and the delivered accessories and cables. ► Read the safety instructions in 2 "Safety instructions" in this Quick Start Guide before using the DTS1 box together with the SPECTANO 100 test device. - Page 20 RC circuit (for more information, see peak to connect to the OUTPUT connector of the front panel of the DTS1 box) to SPECTANO 100 connect to the INPUT connector of SPECTANO 100 Sample 1 to connect to the INPUT connector of...
-
Page 21: Installation
SPECTANO 100 Quick Start Guide Installation Before operating SPECTANO 100 for the first time, use the delivered packing list to verify that all components of the test system are available. DANGER Avoid serious injury or death caused by worn-out, chafed, or otherwise damaged parts of SPECTANO 100 or its accessories. -
Page 22: Power Up Spectano 100
Connect SPECTANO 100 to the computer SPECTANO 100 communicates with the computer through USB interface (see 4 "PC requirements" on page 9). To connect SPECTANO 100 to the computer: 1. Connect the USB 2.0 or higher cable to the USB connector on the SPECTANO 100 rear panel. -
Page 23: Connect Spectano 100 To A Test Object
SPECTANO 100 Quick Start Guide Connect SPECTANO 100 to a test object You can connect SPECTANO 100 to a test cell for liquid or solid materials. This section describes how to connect SPECTANO 100 to the most common test cell types. - Page 24 ► Before handling SPECTANO 100 in any way, connect the test object to ground properly. ► Do not connect or operate SPECTANO 100 with a broken, dirty or oxidized ground terminal or connection cables. ► Do not use power outlets without protective ground (PE).
- Page 25 SPECTANO 100 Quick Start Guide Depending on the connection type of the test cell, OMICRON Lab offers the following adapters: • High-temperature low-noise triaxial-to-BNC adapter with inner and outer shield connected to the BNC outer shield BNC (coaxial) Cable (triaxial)
-
Page 26: Typical Setup For A Test Cell With Guard Ring
Barrier Guard ring Figure 7-4 Connecting SPECTANO 100 to a test cell with guard ring NOTICE The safe area is only safe if the delivered cables and adapters are used. Otherwise, this can also be a danger zone. -
Page 27: Typical Setup For A Test Cell Without Guard Ring
SPECTANO 100 Quick Start Guide To connect SPECTANO 100 to a test cell with guard ring: 1. Ground SPECTANO 100 according to the safety rules (see 2.2 "Five safety rules" on page 5). 2. Connect the standard triaxial cable according to the color code to the SPECTANO 100 OUTPUT and INPUT connectors: •... - Page 28 Otherwise, this can also be a danger zone. To connect SPECTANO 100 to a test cell without guard ring: 1. Ground SPECTANO 100 according to the safety rules (see 2.2 "Five safety rules" on page 5). 2. Connect the standard triaxial cable according to the color code to the SPECTANO 100 OUTPUT and INPUT connectors: •...
-
Page 29: Connect Spectano 100 To The Dts1 Dielectric Test Sample Box
► Before handling SPECTANO 100 in any way, connect the test object to ground properly. ► Do not connect or operate SPECTANO 100 with a broken, dirty or oxidized ground terminal or connection cables. ► Do not use power outlets without protective ground (PE). -
Page 30: Connect Spectano 100 To The Dielectric Sample Holder Dsh 100
Sample 1 connector Connect SPECTANO 100 to the Dielectric Sample Holder DSH 100 Connect SPECTANO 100 to OMICRON Lab’s DSH 100 Dielectric Sample Holder by using the delivered triaxial cables as shown in the following figure Figure 7-7 Connecting SPECTANO 100 to the DSH 100 1. - Page 31 ► Read the safety instructions in this user manual as well as the safety instructions and corresponding chapters in the DSH 100 user manual first. ► Always connect the SPECTANO 100 earth terminal to safety ground using a proper ground connection when voltage levels >30 V or >60...
-
Page 32: Support
Installation Support When you are working with our products we want to provide you with the greatest possible benefits. If you need any support, we are here to assist you! Technical support – get support Send us your requests or questions under www.omicron-lab.com/support support@omicron-lab.com At our technical support hotline, you can reach well-educated technicians for all... - Page 33 Version 3.0 info@omicron-lab.com www.omicron-lab.com © OMICRON Lab, 2020 SPECTANO 100 Quick Start Guide engl. All rights reserved. ENU 1134 03 03...
