9424200994 Rev N
0 – 10 Vdc
Transducer
Transducer
External RTD Input Connections
External 2-wire RTD input connections are shown in Figure 369. Figure 370 shows external 3-wire RTD
input connections.
BE1-11g
Voltage
Figure 367. Analog Inputs - Voltage Input Connections
4 – 20 mA
Current
Figure 368. Analog Inputs - Current Input Connections
RED
BLACK
Jumper
Figure 369. External Two-Wire RTD Input Connections
RTD Module
AIN I+
AIN
AIN V+
RTD Module
AIN I+
AIN
AIN V+
RTD Module
RTD1+
RTD1–
RTD1C
621
