Functional Test Report - Basler BE1-11g Instruction Manual

9424200994 Rev N
Setting
Inverse Time Pickup
Definite Timer 1 Pickup
Definite Timer 1 Time Delay
Alarm Pickup
Step 2: Connect and apply 120 Vac, three-phase, 60-hertz voltage source to Terminals C13 (A-phase),
C14 (B-phase), C15 (C-phase), and C16 (neutral).
Step 3: Step the A-phase voltage to 142.2 V (118.5% or 2.37 V/Hz). Measure the time between the
increase in voltage and the closure of OUT1. Record the result.
Step 4: Repeat steps 1 through 3 for Time Delays of 1 second and 5 seconds. Record the results.
Step 5: (Optional.) Repeat steps 1 through 4 for the B-phase and C-phase voltage inputs.
Step 6: (Optional.) Repeat steps 1 through 5 for settings group 1, 2, and 3.
Step 7: (Optional.) Set Definite Timer 1 Pickup to 0 and Definite Timer 2 Pickup to 2.36 V/Hz and repeat
steps 1 through 6 for Definite Timer 2.

Functional Test Report

Alarm Verification
Alarm Setting Range = 0.5 to 6 V/Hz
Alarm Accuracy = ±2% or ±0.05 V/Hz, whichever is greater
Alarm/Reset Ratio = 98% ±1%
Alarm
Step Low
Setting
6 2.05 2.00 V/Hz
* Reset range is calculated from the alarm setting and may need adjusted based on actual alarm.
Inverse Time Pickup Verification
Pickup Setting Range = 0.5 to 6 V/Hz
Pickup Accuracy = ±2% or ±0.05 V/Hz, whichever is greater
Dropout/Pickup Ratio = 98% ±1%
Pickup
Step Low
Setting
7 2.10 2.05 V/Hz
* Dropout range is calculated from the pickup setting and may need adjusted based on actual pickup.
Definite Time Pickup Verification
Pickup Setting Range = 0.5 to 6 V/Hz
Pickup Accuracy = ±2% or ±0.05 V/Hz, whichever is greater
Dropout/Pickup Ratio = 98% ±1%
BE1-11g
Table 131. Definite Time Verification Test Settings
Value
0 Disables Inverse Time Pickup
2.36 Sets Definite Timer 1 Pickup at 118% of nominal (2.36 V/Hz)
500 Sets Definite Timer 1 Time Delay at 500 ms
0 Disables Alarm Pickup
Actual
High
Alarm
2.10 V/Hz
Actual
High
Pickup
2.15 V/Hz
Description
Actual
Low*
Reset
1.94 V/Hz
Actual
Low*
Dropout
2.037 V/Hz
383
High* Pass/Fail
1.98 V/Hz P / F
High* Pass/Fail
2.079 V/Hz P / F
Overexcitation (24) Test
