Step 2: Apply the voltage values listed in Table 124 and verify voltage-measuring accuracy by using the
Metering Explorer in BESTCOMSPlus to open the Analog Metering, Voltage, Secondary
Voltage screen. The Metering > Analog Metering > Voltage > Secondary Voltage screen of the
front-panel display can also be monitored to verify voltage measurements. Accuracy is ±0.5%.
Step 3: Connect BE1-11g Terminals C17 (polarity) and C18 to a 180 Hz (third harmonic) ac voltage
source.
Step 4: Apply the voltage values listed in Table 124 and verify voltage-measuring accuracy by using the
Metering Explorer in BESTCOMSPlus to open the Analog Metering, Voltage, Secondary
Voltage screen. The Metering > Analog Metering > Voltage > Secondary Voltage screen of the
front-panel display can also be monitored to verify voltage measurements. Accuracy is ±0.5%.
Table 124. Aux Voltage Circuit Verification VX & VX 3
Applied Voltage

Frequency Verification

Step 1: Connect BE1-11g Terminals C13 (polarity) and C16 (A to Neutral of the three-phase voltage
input) to a 60 hertz ac voltage source (line voltage).
Step 2: Connect BE1-11g Terminals C17 (polarity) and C18 (Auxiliary Voltage Input) to a second
60-hertz ac voltage source (bus voltage).
Step 3: Apply 115 volts at 0 degrees and 60 hertz to both sources. Verify the measuring accuracy of the
line and bus frequency by using the Metering Explorer in BESTCOMSPlus to open the Analog
Metering, Frequency screen. The Metering > Analog Metering > Frequency screen of the front-
panel display can also be monitored to verify frequency measurements.
Acceptance Testing
30 volts
50 volts
70 volts
90 volts
110 volts
Measured Voltage
Lower Limit
29.85 V
49.75 V
69.65 V
89.55 V
109.45 V
9424200994 Rev N
rd
Values
Upper Limit
30.15 V
50.25 V
70.35 V
90.45 V
110.55 V
