9424200994 Rev N
Name
Logic Function
Block
50BFI
52BFI
Trip
ReTrip
Operational Settings
Breaker failure element operational settings are configured on the Breaker Fail (50BF) settings screen
(Figure 61) in BESTCOMSPlus. Settings ranges and defaults are summarized in Table 32.
Setting
Mode
Source*
Pickup (Phase & Ground)
Control Timer
Delay Timer
* For protection systems equipped with two sets of CTs.
BE1-11g
Table 31. Logic Inputs and Outputs
Input
Disables the 50BF function when true
Input
Starts the 50BF timer when true
Input
Starts the 50BF timer when true
Output
True after the 50BF Delay Timer expires
Output
True when the 50BF Delay Timer is actively timing
Figure 61. Breaker Fail Settings Screen
Table 32. Operational Settings
Range
Disabled or Enabled
CT Circuit1 or CT Circuit 2
0 or 0.25 to 10.00 (5A CTs)
0 or 0.05 to 2.00 (1A CTs)
0 or 0.01 to 0.5 (SEF)
0 or 50 to 999
0 or 50 to 999
Purpose
Increment
Unit of Measure
n/a
n/a
n/a
n/a
varies
amps
varies
milliseconds
varies
milliseconds
Breaker Failure (50BF) Protection
93
Default
Disabled
CT Circuit 1
0
50
50
