Setting
Mode
Reverse Reach
Forward Reach
Blinder A Offset
Blinder B Offset
Blinder Angle
Blinder Traverse Time
Delay
Trip Delay
Min I1
I2/I1 Ratio
Out of Step (78OOS) Protection
Table 53. Operational Settings
Range
Disabled or Enabled
0 to 500
0 to 500
0 to 500
0 to 500
1 to 90
0 to 10,000
0 to 5,000
5 to 600
10 to 200
9424200994 Rev N
Unit of
Increment
Measure
n/a
n/a
varies
ohms
varies
ohms
varies
ohms
varies
ohms
1
degrees
varies
milliseconds
varies
milliseconds
percent of CT
1
rating
1
percent
Default
Disabled
4
8.5
2.5
2.5
90
100
100
5
10
