Basler BE1-11g Instruction Manual page 520

508
Step Pickup Setting
10.0 V (5 Ω)
5
6 8.00 V
Pickup Verification (mho Characteristic 2)
Step Pickup Setting
10.0 V (5 Ω)
5
6 8.00 V
Timing Verification (mho Characteristic 1)
Time Delay Range = 0 to 300,000 ms
Timing Accuracy = ±0.5% or ±2 cycles, whichever is greater
Step Time Delay Setting
4 2,000 ms
5 1,000 ms
Timing Verification (mho Characteristic 2)
Step Time Delay Setting
4 2,000 ms
5 1,000 ms
Loss of Excitation – Impedance Based (40Z) Test
Low Actual Pickup
9.70 V
7.92 V
Low Actual Pickup
9.70 V
7.92 V
Low Actual Timing
1,967 ms
967 ms
Low Actual Timing
1,967 ms
967 ms
9424200994 Rev N
High Pass/Fail
10.3 V P / F
8.08 V P / F
High Pass/Fail
10.3 V P / F
8.08 V P / F
High Pass/Fail
2,033 ms P / F
1,033 ms P / F
High Pass/Fail
2,033 ms P / F
1,033 ms P / F
BE1-11g
