9424200994 Rev N
Frequency Raise/Lower Continuous Output Verification
Step 1:
Use BESTCOMSPlus to monitor the status of OUT2 (Lower) and OUT3 (Raise).
Step 2:
Connect a balanced, three-phase voltage source of 69.28 Vpn, 60 Hz to BE1-11g terminals C13
(A-phase), C14 (B-phase), C15 (C-phase), and C16 (neutral). Apply a single-phase, 60-hertz
voltage of 69.28 Vpn, ∠0°, to terminals C17 (Vx-phase) and C18 (Vx-neutral). OUT2 and OUT3
should be open.
Step 3:
Slowly increase the frequency of the phase voltage source until OUT2 closes continuously. This
should occur when the source is raised past the Min Slip setting (approximately 60.2 Hz).
Step 4:
Decrease the frequency phase voltage source until OUT2 opens.
Step 5:
Slowly decrease the frequency of the phase voltage source until OUT3 closes. This should
occur when the source is lowered past the Min Slip setting (approximately 59.8 Hz).
Step 6:
(Optional.) Repeat steps 2 through 5 for settings group 1, 2, and 3.
Breaker Close Attempts/Sync Fail Activation Delay Verification
Step 1:
Use BESTCOMSPlus to verify the settings in Table 235 to the BE1-11g and set the logic in
Figure 316.
Setting
Breaker Close
Attempts
Sync Fail Activation
Delay (s)
Step 2:
Prepare to monitor the status of OUT1 (Close Breaker) and OUT8 (Sync Fail).
Step 3:
Connect a balanced, three-phase voltage source of 69.28 Vpn, 60 Hz to BE1-11g terminals C13
(A-phase), C14 (B-phase), C15 (C-phase), and C16 (neutral). Apply a single-phase, 60-hertz
voltage of 69.28 Vpn, ∠0°, to terminals C17 (Vx-phase) and C18 (Vx-neutral). OUT1 and OUT8
should remain open.
Step 4:
Apply contact sensing voltage to B3 (IN2+) and B4 (IN2-) to initiate a close attempt and cause
OUT1 to close. CAUTION: Applying voltage above the capabilities of the equipped power
supply could cause irreversible damage to the BE1-11g. Consult the
more information on contact input voltage ranges.
Step 5:
OUT1 should make a total of three close attempts. OUT8 should close approximately 5 seconds
after the third close attempt.
Step 6:
(Optional.) Repeat steps 2 through 5 for settings group 1, 2, and 3.
BE1-11g
Table 235. Sync Fail Settings PLL (25A)
BESTCOMSPlus
Value
Screen
3
Control, Synchronizer
(25A)
5
Control, Synchronizer
(25A)
Description
Sets the maximum number of allowable
breaker close attempts to 3
Sets the activation delay for the sync fail
alarm to 5 seconds
Specifications
Synchronizer (25A) Test
517
chapter for
