Step Time Delay Setting
4 2,000 ms
5 5,000 ms
5 10,000 ms
Pickup Verification (3I0 Mode)
Pickup Setting Range = 0.5 to 150 A for 5A sensing
Pickup Accuracy =
Dropout should occur between 93-99% of the actual pickup value.
Step Pickup Setting
6 0.5 A (5A CT)
7 5.0 A (5A CT)
7 20.0 A (5A CT)
6 0.1 A (1A CT)
7 1.0 A (1A CT)
7 4.0 A (1A CT)
* Dropout range is calculated from the pickup setting and may need adjusted based on actual pickup.
Timing Verification (3I0 Mode)
Time Delay Range = 0 to 60,000 ms
Timing Accuracy = ±1% or ±½ cycle, whichever is greater + 3 cycles max for currents 1.5 x pickup
Step Time Delay Setting
4 2,000 ms
5 5,000 ms
5 10,000 ms
Pickup Verification (I2 Mode)
Pickup Setting Range = 0.5 to 150 A for 5A sensing
Pickup Accuracy =
BE1-11g
Low
1,942 ms
4,927 ms
9,902 ms
0.1 to 30 A for 1A sensing
±3% or ±75 mA, whichever is greater for 5A sensing
±3% or ±15 mA, whichever is greater for 1A sensing
Low Actual Pickup
0.425 A
4.85 A
19.4 A
0.085 A
0.97 A
3.88 A
Low
1,942 ms
4,927 ms
9,902 ms
0.1 to 30 A for 1A sensing
±3% or ±75 mA, whichever is greater for 5A sensing
±3% or ±15 mA, whichever is greater for 1A sensing
Actual Timing
High Low* Actual Dropout
0.575 A 0.465 A
5.15 A 4.65 A
20.6 A 18.6 A
0.115 A 0.093 A
1.03 A 0.93 A
4.12 A 3.72 A
Actual Timing
Instantaneous Overcurrent (50) Test
High Pass/Fail
2,058 ms P / F
5,073 ms P / F
10,098 ms P / F
High* Pass/Fail
0.495 A P / F
4.95 A P / F
19.8 A P / F
0.099 A P / F
0.99 A P / F
3.96 A P / F
High Pass/Fail
2,058 ms P / F
5,073 ms P / F
10,098 ms P / F
