Virtual Control Switches (43) Test

Functional testing is a way to assess this protection system's suitability for your application. Functional
testing goes beyond the more basic tests found in acceptance testing, but lacks the detailed function
testing that is part of the commissioning process.
Test each of the following functions to verify that this BE1-11g measures accurately, is within specified
tolerances, and operates correctly. These tests are also suitable for assisting in systematic
troubleshooting in the event that an operation is questioned. Revisiting the test of a specific function can
help verify whether the BE1-11g is operating within specified tolerances. For further assistance, contact
Basler Electric, Technical Sales Support.
Refer to the
Terminals and Connectors
Reset all targets prior to each test by navigating to the Metering > Status > Targets screen and pressing
the front-panel Reset key. Enter the appropriate username and password if prompted. Clear all logic prior
to each test by using the Settings Explorer in BESTCOMSPlus® to open the BESTlogic™Plus
Programmable Logic screen and click the Clear button located on the toolbar. After new BESTlogicPlus
settings are made, click the Save button located on the toolbar to compile BESTlogicPlus. Upload
BESTlogicPlus settings by selecting Upload Logic to Device from the Communication pull-down menu.
Operational settings can be sent by selecting Upload Settings to Device from the Communication pull-
down menu or by clicking the Send Settings button on the toolbar.
The actual operating time of an output contact is equal to the recognition time plus the time delay setting
(accuracy) plus 6 milliseconds. Output contact operating time depends upon the type of test set used and
its operating characteristics.
A Functional Test Report is included at the end of this chapter. It should be used to record the results and
verify pickup and timing accuracy.
Refer to the
Virtual Control Switches (43)

Functional Test Procedure

Switch/Pulse Mode
Step 1:
Use BESTCOMSPlus to send the operational settings in Table 240 to the BE1-11g.
Setting
43-1 Mode
Switch/Pulse
43-1 Name
Test
Label
43-1 On Label
On
43-1 Off Label
Off
Step 2:
Use BESTCOMSPlus to configure the BESTlogicPlus programmable logic shown in Figure 319.
All inputs are set to logic 0.
OUT1 closes when 43-1 output is true.
Step 3:
Prepare to monitor the virtual switch operation. An ohmmeter or continuity tester can be used to
monitor the contact status of OUT1.
BE1-11g
chapter for terminal locations and connections.
chapter for more information on this function.
Table 240. Operational Settings
Value
BESTCOMSPlus Screen
Control, Virtual Control Switches
(43)
Control, Virtual Control Switches
(43)
Control, Virtual Control Switches
(43)
Control, Virtual Control Switches
(43)
Description
Sets 43-1 to Switch/Pulse
mode
Names 43-1 Name label to
"Test"
Names 43-1 On label to "On"
Names 43-1 Off label to "Off"
Virtual Control Switches (43) Test
527
