Basler BE1-11g Instruction Manual page 571

9424200994 Rev N
59X - Auxiliary Overvoltage Protection
Pickup
Setting Range ........................................................... 1 to 150 V
Accuracy.................................................................... ±2% or ±1 V, whichever is greater
Dropout/Pickup Ratio ................................................ 98% ±1%
Timing Mode
Definite Timing
Setting Range ........................................................... 50 to 600,000 ms
Accuracy.................................................................... ±0.5% or ±2 cycles, whichever is greater
Inverse Timing
Setting Range ........................................................... 0 to 9.9
Accuracy.................................................................... ±5% or ±2 cycles, whichever is greater
60FL - Fuse Loss
Time Delay ................................................................ Fixed at 50 ms
62 - Logic Timers
Modes ........................................................................ Pickup/Dropout, One-Shot/Non-Retriggerable,
Setting Range ........................................................... 0 to 9,999,000 ms
Accuracy.................................................................... ±0.5% or ±12 ms, whichever is greater
67/67N - Directional Current and Polarization Protection
Modes ........................................................................ Forward, Reverse, Non-directional
Maximum Torque Angle ............................................ 0 to 359.9°
Polarization Methods
●
Zero Sequence Current Polarization (IG)
●
Negative Sequence Polarization (Q)
●
Zero Sequence Polarization (V)
○
VOIN - Calculated Zero Sequence Voltage compared to Calculated Zero Sequence Current.
○
VOIG - Calculated Zero Sequence Voltage compared to Measured Ground Current.
○
VXIN - Measured 3V0-VX Input compared to Calculated Zero Sequence Current.
○
VXIG - Measured 3V0-VX Input compared to Measured Ground Current.
78OOS - Out of Step Protection
Reverse/Forward Reach
Setting Range ........................................................... 0 to 500 Ω
Accuracy
5 Ampere CT .......................................................... ±3% or ±0.2 Ω, whichever is greater from –100 to 100 Ω
1 Ampere CT .......................................................... ±3% or ±0.2 Ω, whichever is greater from –500 to 500 Ω
Blinder A/Blinder B Offset
Setting Range ........................................................... 0 to 500 Ω
Accuracy
5 Ampere CT .......................................................... ±3% or ±0.2 Ω, whichever is greater from –100 to 100 Ω
1 Ampere CT .......................................................... ±3% or ±0.2 Ω, whichever is greater from –500 to 500 Ω
BE1-11g
Refer to the Time Curve Characteristics
for information on available timing curves.
One-Shot/Retriggerable, Oscillator, Integrating
Timer, Latched
559
chapter
Specifications
