Output Contacts
Make and Carry for Tripping Duty ............................. 30 A for 0.2 seconds per IEEE Std C37.90-2005 -
Break Resistive or Inductive ...................................... 0.3 A at 125 or 250 Vdc (L/R = 0.04 maximum)
Terminals
OUT 1 ........................................................................ C1, C2
OUT 2 ........................................................................ C3, C4
OUT 3 ........................................................................ C5, C6
OUT 4 ........................................................................ C7, C8
OUT 5 ........................................................................ C9, C10
OUT 6 (Optional) ....................................................... E11, E12
OUT 7 (Optional) ....................................................... E9, E10
OUT 8 (Optional) ....................................................... E7, E8
OUT A ....................................................................... C11, C12
Contact-Sensing Inputs
Maximum Input Voltage
The maximum input voltages are the highest voltage for each power-supply range listed under the Power
Supply section.
Turn-On Voltage
Contact-sensing turn-on voltages are listed in Table 249.
Style Option
Gxx1xxxxxxxxxx
Gxx2xxxxxxxxxx
Gxx3xxxxxxxxxx
* AC voltage ranges are calculated using the default recognition time (4 ms) and debounce time (4 ms).
† Voltage ranges depend on jumper configurations. See the
information.
Input Burden
Burden values shown in Table 250 assume nominal value of input voltage applied.
Style Option
Gxx1xxxxxxxxxx
Gxx2xxxxxxxxxx
Gxx3xxxxxxxxxx
Specifications
Table 249. Contact-Sensing Turn-On Voltages
Nominal Input Voltage
48 Vdc or 125 Vac/dc
125/250 Vac/dc
24 Vdc
Table 250. Contact-Sensing Input Burden
Nominal Input Voltage
48 Vdc or 125 Vac/dc
125/250 Vac/dc
24 Vdc
IEEE Standard for Relays and Relay Systems
Associated with Electric Power Apparatus;
7 A continuous AC or DC
Contact-Sensing Turn-On Voltage*
Jumper Installed
(Low Position) †
26 to 38 Vdc
69 to 100 Vdc
56 to 97 Vac
n/a
Contact Inputs and Outputs
Burden
Jumper Installed
(Low Position)
22 kΩ
66 kΩ
n/a
9424200994 Rev N
Jumper Not Installed
(High Position) †
69 to 100 Vdc
56 to 97 Vac
138 to 200 Vdc
112 to 194 Vac
Approx. 5 Vdc
chapter for more
Jumper Not Installed
(High Position)
53 kΩ
123 kΩ
6 kΩ
