9424200994 Rev N
Name
Automatic
D0, D1, D2, D3
SG0, SG1, SG2, SG3
SGCACTIVE
SGCLOVRD
Operational Settings
Setting group operational settings are configured on the Setting Group Setup screen (Figure 120) in
BESTCOMSPlus. Setting ranges and defaults are summarized in Table 71.
BE1-11g
Figure 119. Setting Group Logic Block
Table 70. Logic Inputs and Outputs
Logic
Function
True when automatic control is enabled and false when logic
Input
control is enabled
Inputs
Meaning depends upon the Mode setting
Outputs
True for the active setting group
Output
True when Setting Group Control is Active
Output
True when Setting Group Control is overridden by logic
Purpose
Setting Groups
179
