620
PWR
1
PWR
2
GND
3
4
N.O.
COMM
5
N.C.
6
RTD2+
7
RTD2-
8
COMM
9
RTD4-
10
RTD4+
11
RTD6+
12
RTD6-
13
COMM
14
RTD8-
15
RTD8+
16
RTD10+
17
18
RTD10-
COMM
19
RTD12-
20
21
RTD12+
Connector
TB1
J4
J5
P3
P4
External Analog Input Connections
Voltage input connections are shown in Figure 367 and current input connections are shown in Figure
368. When using the current input, AIN V+ and AIN I+ must be tied together.
RTD Module
TB1
J5
J4
22
RTD1+
23
RTD1-
24
COMM
25
RTD3-
26
RTD3+
27
RTD5+
28
RTD5-
29
COMM
30
RTD7-
31
RTD7+
32
RTD9+
33
RTD9-
34
COMM
35
RTD11-
36
RTD11+
P0061-54
Figure 366. Input and Output Terminals
Table 256. Input and Output Terminals
Operating Power and Alarm Contacts
RTD Inputs 1, 3, 5, 7, 9, 11
RTD Inputs 2, 4, 6, 8, 10, 12
Analog Outputs 1 - 4 and RS485 Connection
Analog Inputs 1 - 4
P4
AIN4I+
60
AIN4-
59
AIN4V+
58
AIN3I+
57
AIN3-
56
AIN3V+
55
AIN2I+
54
AIN2-
53
AIN2V+
52
AIN1I+
51
AIN1-
50
AIN1V+
49
Description
9424200994 Rev N
P3
48
RS485 C
47
RS485 B
46
RS485 A
45
NO CONN
44
AOUT4-
43
AOUT4+
42
AOUT3-
41
AOUT3+
40
AOUT2-
39
AOUT2+
38
AOUT1-
37
AOUT1+
BE1-11g
