Step 2: Prepare to monitor the 27X-1 timings. Timing accuracy is verified by measuring the elapsed
time between a sensing voltage change and OUT1 closing.
Step 3: Connect and apply a 75 Vac, single-phase voltage source to terminals C13 (A-phase) and C16
(Neutral).
Step 4: Step the voltage down to 55 volts. Measure the time delay and record the result.
Step 5: Repeat step 4 for the 5,000 ms and 10,000 ms time delay settings of Table 141. Record the
results.
Step 6: (Optional.) Repeat steps 1 through 5 and 5 for settings group 1, 2, and 3.
Step 7: (Optional.) Repeat steps 1 through 6 for 27X-2, 27X-3, and 27X-4.
Pickup Verification (V1 Mode)
Step 1: Use BESTCOMSPlus to send the operational settings in Table 142 to the BE1-11g. Reset all
targets.
Setting
Phase VT Ratio 1
Phase VT 4W-Y
Connection
27/59 Mode PN
Element Mode V1
Inhibit Level 10 V
Timing Mode Definite
27X-1 V1 Enabled
Step 2: Use BESTCOMSPlus to configure the BESTlogicPlus programmable logic shown in Figure 281.
•
Blocking is disabled.
•
OUT1 closes for 27X-1 Trip.
•
OUT2 closes for 27X-1 Pickup.
•
Fault recording is enabled.
Step 3: Use BESTCOMSPlus to open the Protection, Voltage, Undervoltage (27X-1) screen and send
the first row of test settings in Table 143 to the BE1-11g.
BE1-11g
Table 141. Timing Test Settings (3V0 Mode)
Pickup Setting
65 V
65 V
65 V
Table 142. Operational Settings (V1 Mode)
Value BESTCOMSPlus Screen
System Parameters, Sensing
Transformers
System Parameters, Sensing
Transformers
System Parameters, Sensing
Transformers
Protection, Voltage, Undervoltage
(27X-1)
Protection, Voltage, Undervoltage
(27X-1)
Protection, Voltage, Undervoltage
(27X-1)
Target Configuration, Targets
Time Delay
2,000 ms
5,000 ms
10,000 ms
Description
Sets phase VT ratio to 1
Sets phase VT connection to
4W-Y
Sets 27/59 mode to phase-
neutral
Enables 27X-1 function for V1
mode
Sets inhibit level to 10 V
Selects definite timings
Enables V1 target for 27X-1
Auxiliary Undervoltage (27X) Test
