Zero-Sequence Current Polarization
Use setup commands in Table 212. Using Table 218 as a guide, send the settings to the BE1-11g.
Table 218. Directional, Current-Polarizing, Neutral Operational Settings
Setting
Polarization IG=checked
Method Q=unchecked
V=unchecked
Pickup 0 A
Pickup 2.0 A
Pickup 0 A
Step 1: Apply 2 Aac current at 0 degrees to the independent ground input IG, terminals D7 (polarity)
and D8 (non-polarity). No ac voltage is required for this test.
Step 2: From a second current source, apply 0 amp A-phase current at an angle of 0 degrees and
slowly increase the current until OUT2 closes. Decrease A-phase current until OUT2 just drops
out. Pickup will occur within ±2% of the 50-2 pickup setting (1.96 A to 2.04 A). Dropout will
occur at approximately 95% of the actual pickup value. Verify that there is a 50-2-67-Residual
target on the front-panel display.
Step 3: With the same polarizing current applied, increase the A-phase current until OUT2 closes.
Swing the angle of the applied current +90 degrees and –90 degrees away from the 0. Verify
that OUT2 opens at approximately 90 degrees lagging and 270 degrees lagging. OUT2 should
remain closed from 90 through 0 to 270 degrees lagging (defined as forward trip direction).
Step 4: Repeat steps 1 through 4 for "Reverse Polarization by selecting Reverse direction on the
Protection, Current, Instantaneous Overcurrent (50-2) screen. BE1-11g operation will occur at
180 degrees lagging. Swing the angle of the applied current +90 degrees and –90 degrees
away from the 180 degrees. Verify that OUT2 opens at approximately 90 degrees lagging and
270 degrees lagging. OUT2 should remain closed from 90 through 180 to 270 degrees lagging
(defined as reverse trip direction).
Step 5: (Optional.) Repeat steps 1 through 5 for 50-4, 50-5, and 50-6. Setup commands in Table 212
and operational settings in Table 218 must be modified accordingly.
Step 6: (Optional.) Repeat steps 1 through 5 for settings group 1, 2, and 3.

Functional Test Report

Steps
4-6 Positive-Sequence Voltage Polarizing, Phase Overcurrent Elements
7-10 Negative-Sequence Voltage Polarizing, Phase Overcurrent Elements
11-18 Negative-Sequence Voltage Polarizing, Negative-Sequence Overcurrent Elements
19-22 Negative-Sequence Voltage Polarizing, Ground Overcurrent Elements
23-32 Zero-Sequence Voltage Polarizing, Ground Overcurrent Elements
1-6 Zero-Sequence Current Polarization
BE1-11g
Value BESTCOMSPlus Screen
Protection, Current, Polarization
(67N)
Protection, Current, Instantaneous
Overcurrent (50-1)
Protection, Current, Instantaneous
Overcurrent (50-2)
Protection, Current, Instantaneous
Overcurrent (50-3)
Function
Description
Selects zero sequence
current polarization
Sets 50-1 pickup to 0 amps
Sets 50-2 pickup to 2.0
amps
Sets 50-3 pickup to 0 amps
Pass/Fail
P / F
P / F
P / F
P / F
P / F
P / F
